Lennox LGT210H User Manual

Page 45
508288-01 9/2022
300 CHARGING CURVE CIRCUIT 2 - NO REHEAT - ALL-ALUMINUM COIL - 581098-01
Suction Pressure (psig)
70
80
90
100
110
120
Outdoor Temperature (°F)
105°
95°
115°
85°
75°
65°
60
-
110 120 130 140 150 160 170
300 CHARGING CURVE CIRCUIT 3 - NO REHEAT - ALL-ALUMINUM COIL - 581098-01
Suction Pressure (psig)
Outdoor Temperature (°F)
105°
95°
115°
85°
75°
65°
70
80
90
100
110
120
60
110 120 130 140 15010090
