Lennox LI036CI-180P432 - Explanation of Symbols

Service Manual
9. Troubleshooting
..................................................................................................46
9.1 Flashing LED of Indoor/Outdoor Unit and Primary Judgement ......................................46
9.2 How to Check Simply the Main Part ...............................................................................55
9.3 Troubleshooting for Normal Malfunction .........................................................................71
10. Exploded View and Parts List
..............................................................73
10.1 Indoor Unit ....................................................................................................................73
10.2 Outdoor Unit .................................................................................................................75
11. Removal Procedure
.......................................................................................77
11.1 Removal Procedure of Indoor Unit ...............................................................................77
11.2 Removal Procedure of Outdoor Unit ............................................................................86
Appendix:
........................................................................................................................92
Appendix 1: Reference Sheet of Celsius and Fahrenheit ....................................................92
Appendix 2: Conguration of Connection Pipe ..................................................................... 92
Appendix 3: Pipe Expanding Method ...................................................................................93
Appendix 4: List of Resistance for Temperature Sensor ......................................................94
Table of Contents
