Technical Information
Service Manual
Symbol Symbol Color Symbol Symbol Color Symbol Name
WH White GN Green Grounding wire
YE Yellow BN Brown COMP Compressor
RD Red BU Blue CAP Jumper Cap
YEGN Yellow/Green BK Black / /
VT Violet OG Orange / /
5. Electrical Part
5.1 Wiring Diagram
● Indoor Unit
● Instruction
Note: Jumper cap is used to determine fan speed and the swing angle of horizontal lover for this model.
3
2
