Installation and Maintenance
Service Manual
a
b
a
b
c
6.Remove top cover of electric box
7.Remove front case
screw
top cover of electric box
screw cap
screw
front case
ProcedureSteps
Remove screws fixing the top cover of electric box.
Remove the top cover of electric box.
Remove the screw caps on front case.
Remove screws connecting the front case.
Remove the front case.
