Lennox LM036HI-100P432 User Manual

remote controller
NOTICE:
Actual product may be different from above graphics, please refer to actual
products.
Outdoor Unit
air inlet
Connection wire
air outlet
7
(Display content or position may be different from above
graphics, please refer to actual products)
Parts name
Indoor Unit
air inlet
panel
filter
aux.button
horizontal louver
air outlet
heating
indicator
temp.
indicator
cooling
indicator
power
indicator
receiver
window
drying
indicator
display
For some model:
For some model:
temp.
heating
indicator
indicator
cooling
indicator
power
indicator
receiver
window
drying
indicator
display

Lennox LM036HI-100P432 Specifications

General

Model	LM036HI-100P432
SEER Rating	16
Refrigerant	R-410A
Voltage	208/230V
Phase	1
Type	Air Conditioner
Cooling Capacity	36000 BTU/h
Dimensions (Outdoor Unit)	35" x 30" x 28"
