Lennox LM036HI-100P432

Installation dimension diagram
At least 250cm
At least 15cm
At least 300cm
Space to the ceiling
Space to the obstruction
At least 15cm
At least 15cm
Space to the wall
Space to the wall
Space to the wall
Above
Above
mc03
50cm
Air inlet side
00
Space to the obstruction
Air outlet side
02 mc0
Above
Above
30cm
Space to the wall
mc05
evobA
21
