Blower Data – LRP16HP
LRP16HP24 Blower Performance
0 through 0.80 in. w.g. External Static Pressure Range
“ADJUST”
Jumper
Setting
Blower Control Jumper Speed Positions
“COOL” Speed - cfm “HEAT” Speed - cfm“CONTINUOUS FAN” Speed - cfm
A
1
BC DA
1
BC DABCD
+1100 880 660 440 1150 1035 690690 550440 330220
NORM 1000 800 600 400 1000 900 600600 500400 300200
— 900 720 540 360 1000 900 600600 450360 270180
LRP16HP36 Blower Performance
0 through 0.80 in. w.g. External Static Pressure Range
“ADJUST”
Jumper
Setting
Blower Control Jumper Speed Positions
“COOL” Speed - cfm “HEAT” Speed - cfm“CONTINUOUS FAN” Speed - cfm
A
1
BC DA
1
BC DABCD
+ 1430 1320 1100 880 1495 1380 1150 1150 715660 550440
NORM 1300 1200 1000 800 1300 1250 1000 1000 650600 500400
—1170 1080 900 720 1300 1200 1000 1000 585540 450360
LRP16HP48 Blower Performance
0 through 0.80 in. w.g. External Static Pressure Range
“ADJUST”
Jumper
Setting
Blower Control Jumper Speed Positions
“COOL” Speed - cfm “HEAT” Speed - cfm“CONTINUOUS FAN” Speed - cfm
A
1
BC DA
1
BC DABCD
+ 1980 1760 1540 1320 2070 1840 1610 1610 990880 770660
NORM 1800 1600 1400 1200 1800 1600 1400 1400 900800 700600
— 1620 1440 1260 1080 1800 1600 1400 1400 810720 630540
LRP16HP60 Blower Performance
0 through 0.80 in. w.g. External Static Pressure Range
“ADJUST”
Jumper
Setting
Blower Control Jumper Speed Positions
“COOL” Speed - cfm “HEAT” Speed - cfm“CONTINUOUS FAN” Speed - cfm
A
1
BC DA
1
BC DABCD
+ 2200 1980 1760 1540 2300 2070 1840 1840 1100 990880 770
NORM 2000 1800 1600 1400 2000 1800 1600 1600 1000 900800 700
— 1800 1620 1440 1260 2000 1800 1600 1600 900810 720630
1
Factory Settings.
NOTE-Allairdataismeasuredexternaltounitwithoutair
NOTE-1stStage is70%of2ndStage (fullcapacity)incoolingmode.
