Lennox MCC Series Installation, Operating And Maintenance

Installation - Operation - Maintenance manual (IOM) • AIR COOLED CHILLERS & SPLIT UNITS - 1106-E • 60 •
Size
702V 752VE 803V 853VE 953V 1003VE
Operating limits for Evaporator
Water Test pressure Bar 10
Refrigerant Test pressure Bar 26,5
Water Max. operating pressure Bar 6
Refrigerant Max. operating pressure Bar 26,5
Water Min. flow
m3/h
8°C
∆ T
Water Max. flow m3/h 153,5 153,5 153,5 153,5 180 180
Operating limits for Pressure gauge control
Safety Cut of low pressure Bar 0,7
Safety Interlocking of low pressure Bar 2,2
Safety Cut of high pressure Bar 26,5
Safety Interlocking of high pressure Bar 20
Size
1053V 1153VE 1254V 1354VE 1404V 1504VE
Operating limits for Evaporator
Water Test pressure Bar 10
Refrigerant Test pressure Bar 26,5
Water Max. operating pressure Bar 6
Refrigerant Max. operating pressure Bar 26,5
Water Min. flow
m3/h
8°C
∆ T
Water Max. flow m3/h 220 220 220 220 250 250
Operating limits for Pressure gauge control
Safety Cut of low pressure Bar 0,7
Safety Interlocking of low pressure Bar 2,2
Safety Cut of high pressure Bar 26,5
Safety Interlocking of high pressure Bar 20
