ML14XC1 - 1.5 to 5 Ton Air Conditioner / Page 10
AHRI STANDARD 210/240
Cooling or heating capacities are net values, including
the effects of blower motor heat, and do not include
supplementary heat. Power input is the total power input
to the compressor(s) and fan(s), plus any controls and
other items required as part of the system for normal
operation.
Units which do not have an indoor air-circulating blower
furnished as part of the model, i.e., split system with
indoor coil only, is established by subtracting from the
total cooling capacity 1250 Btu/h per 1,000 cfm, and by
adding the same amount to the heating capacity. Total
power input for both heating and cooling is increased by
365 W per 1,000 cfm of indoor air circulated.
TXV/ORIFICE USAGE
Use this table for C33, C35, CH23, CH33, CH35 and CR33
Field Installed TXV/Orice Match-Ups.
Model Refrigerant Metering Orice
(RFC)
Thermal
Expansion
Valve (TXV)
Order No. Orice Size
018 10W94 0.052 12J18
024 10W97 0.060 12J18
030 11W00 0.067 12J18
036 11W01 0.071 12J19
041 N/A N/A 12J20
042 11W06 0.081 12J20
047 N/A N/A 12J20
048 11W07 0.083 12J20
059 N/A N/A 12J20
060 11W14 0.096 12J20
CX34, CX35 upow coils and all Lennox air handlers are shipped with a factory
installed TXV. In most cases, no change out of the valve is needed.
If a change out is required it will be listed in the “TXV SUBSTITUTIONS” table.
The correct TXV must be ordered separately and eld installed.
C33, C35, CH33 and CH35 coils - Use the orice shipped with the outdoor unit
or replace the factory installed orice with the expansion valve listed.
CR33 and CH23 coils - Use the orice shipped with the outdoor unit or use the
expansion valve listed.
MOST POPULAR MATCHES
Outdoor Unit
Model
Indoor Unit
Model No
018 CX34-25
024 CX34-25
030 CX34-31
036 CX34-38
041 CX34-49
042 CX34-49
047 CX34-62C
048 CX34-62C
059 CX34-62C
060 CX34-62C
*TXV SUBSTITUTIONS
Use this table to determine if the factory installed TXV in
the indoor unit needs to be replaced.
Model
Indoor Coil or Air
Handler
Factory
TXV
Replacement
TXV
030 CX35-48 12J20 12J18
030 CX34-42 12J20 12J18
030 CX34-43 12J20 12J18
030 CX35-48 12J20 12J18
041 CX34-38 12J19 12J20
041 CX35-36 12J19 12J20
* CX34 coils and all air handlers - The factory installed expansion valve must
be replaced with the expansion valve listed (ordered separately).
If the combination is not listed above, the factory installed TXV is used.

Lennox MERIT ML14XC1 Specifications

General

Compressor Type	Single-stage
Refrigerant	R-410A
Energy Star Certified	No
Cooling Capacity (BTU/h)	18, 000 - 60, 000
Operating Voltage (VAC)	208/230
Unit Weight (lbs)	Varies by model
Dimensions (H x W x D, inches)	Varies by model
Cooling Capacity	1.5 to 5 tons
Warranty	5-Year Limited Warranty on covered components
