Lennox Merit Series User Manual

13
NOTE: DIAGRAMS & ILLUSTRATIONS ARE NOT TO SCALE.
LENNOX HEARTH PRODUCTS • MERIT
®
SERIES DIRECT-VENT CONTEMPORARY DESIGN GAS FIREPLACES • MODEL MLDVTCD-35 • CARE AND OPERATION
Figure 6
MLDVTCD-35 REFRACTORY PANELS AND CONTEMPORARY MEDIA PLACEMENT
Detail A
Rear Zen Garden Panel
Burner Outlet
Detail B
Burner Outlet
Left Zen Garden Panel
Right Zen Garden Panel
Black Obsidian Contemporary Glass
Detail C
Detail D
Diamond White Contemporary Glass
Burner Outlet
Tumbled River Stone
Burner Outlet
Contemporary Beach Sand
(Note: River Stone And Beach Sand May Be Used Together)
(Note: Beach Sand And River Stone May Be Used Together)
