Page 17
Integrated Control
FIGURE 25
INTEGRATED CONTROL
(Automatic Hot Surface Ignition System)
TERMINAL DESIGNATIONS
HUM - Humidifier 240VAC
LINE - Input 240VAC
XFMR - Transformer 240VAC
EAC - Electronic Air Cleaner 240VAC
COOL - Cool Speed 240VAC
PARK1, PARK2 - Dead terminals for alternate speed taps
NEUTRALS - Neutral terminals 240VAC
HEAT - Heating Speed 240VAC
FS - Flame Sense
