Lennox ML180UHA - Specifications; Ml180 Uh070 Ap36 A; Ml180 Uh090 Ap48 B; Ml180 Uh110 Ap36 C

Page 24
SPECIFICATIONS
Gas
Heating
Performance
Model Number ML180UH070AP36A ML180UH090AP48B ML180UH110AP36C
Australian Gas Association
Energy Rating - Stars
3.7 3.7 3.7
Input - Mj/h 69.6 92.8 116.1
Output - kW 15.5 20.6 25.8
Temperature rise range - °C 14 - 31 14 - 31 19 - 36
Gas Manifold Pressure (kPa)
Natural Gas / Propane
0.87 / 2.30 0.87 / 2.30 0.87 / 2.30
High Static - Pa 125 125 125
Connections Flue connection - mm round 102 102 102
Gas pipe size IPS 1/2 in. 1/2 in. 1/2 in.
Indoor
Blower
Wheel nom. diameter x width - mm 254 x 203 254 x 254 254 x 254
Motor output - W 248 373 373
Add-on cooling - kW 7-10.6 7-14.1 7-14.1
Air Volume Range - L/s 282 - 716 229 - 890 239 - 827
Electrical Data Voltage 220/240 volts - 50 hertz - 1 phase (less than 10 amps)
Shipping Data kg - 1 package 54 63 70
NOTE - Filters and provisions for mounting are not furnished and must be eld provided.
SPECIFICATIONS
Gas
Heating
Performance
Model Number ML180UH110AP60C ML180UH135AP60D
Australian Gas Association
Energy Rating - Stars
3.7 3.7
Input - Mj/h 116.1 139.3
Output - kW 25.8 31.0
Temperature rise range - °C 17 - 33 17 - 33
Gas Manifold Pressure (kPa)
Natural Gas / Propane
0.87 / 2.30 0.87 / 2.30
High Static - Pa 125 125
Connections Flue connection - mm round 102 102
Gas pipe size IPS 1/2 in. 1/2 in.
Indoor
Blower
Wheel nom. diameter x width - mm 292 x 254 279 x 279
Motor output - W 746 746
Add-on cooling - kW 14.1-17.6 14.1-17.6
Air Volume Range - L/s 633 - 1138 602 - 1159
Electrical Data Voltage 220/240 volts - 50 hertz - 1 phase (less than 10 amps)
Shipping Data kg - 1 package 71 79
NOTE - Filters and provisions for mounting are not furnished and must be eld provided.
