Lennox MMDB Service Manual

59
Table 5. MPC Multi-Zone System Combinations
NOTE - For multi-zone systems, the total capacity of all indoor units must be 66% to 133% of the outdoor unit capacity.
Outdoor Unit
Model No.
Number
of
Zones
Indoor Unit
Capacity
Nominal Cooling Capacity at Rated
System Capacity (Btuh)
Nominal Heating Capacity at Rated
System Capacity (Btuh)
#1 #2 #3 #4 #5 #1 #2 #3 #4 #5 #1 #2 #3 #4 #5
MPC048S4M
3
9K 18K 24K - - - - - - 8,000 16,000 21,000 - - - - - - 8,400 16,800 22,300 - - - - - -
9K 18K 30K - - - - - - 7,000 15,000 25,000 - - - - - - 8,100 16,100 26,700 - - - - - -
9K 18K 36K - - - - - - 7,000 14,000 28,000 - - - - - - 7,800 15,500 30,900 - - - - - -
9K 24K 24K - - - - - - 7,000 20,000 20,000 - - - - - - 8,100 21,400 21,400 - - - - - -
9K 24K 30K - - - - - - 7,000 19,000 23,000 - - - - - - 7,800 20,600 25,700 - - - - - -
12K 12K 12K - - - - - - 12,000 12,000 12,000 - - - - - - 12,800 12,800 12,800 - - - - - -
12K 12K 18K - - - - - - 11,000 11,000 17,000 - - - - - - 12,100 12,100 18,100 - - - - - -
12K 12K 24K - - - - - - 11,000 11,000 22,000 - - - - - - 11,500 11,500 22,900 - - - - - -
12K 12K 30K - - - - - - 10,000 10,000 26,000 - - - - - - 10,900 10,900 27,300 - - - - - -
12K 12K 36K - - - - - - 10,000 10,000 29,000 - - - - - - 10,500 10,500 31,400 - - - - - -
12K 18K 18K - - - - - - 11,000 16,000 16,000 - - - - - - 11,500 17,200 17,200 - - - - - -
12K 18K 24K - - - - - - 10,000 15,000 20,000 - - - - - - 10,900 16,400 21,800 - - - - - -
12K 18K 30K - - - - - - 10,000 14,000 24,000 - - - - - - 10,500 15,700 26,200 - - - - - -
12K 24K 24K - - - - - - 10,000 19,000 19,000 - - - - - - 10,500 21,000 21,000 - - - - - -
18K 18K 18K - - - - - - 15,000 15,000 15,000 - - - - - - 16,400 16,400 16,400 - - - - - -
18K 18K 24K - - - - - - 14,000 14,000 19,000 - - - - - - 15,700 15,700 21,000 - - - - - -
4
6K 6K 6K 18K - - - 6,000 6,000 6,000 18,000 - - - 6,500 6,500 6,500 19,400 - - -
6K 6K 6K 24K - - - 6,000 6,000 6,000 24,000 - - - 6,300 6,300 6,300 25,100 - - -
6K 6K 6K 30K - - - 6,000 6,000 6,000 29,000 - - - 6,100 6,100 6,100 30,100 - - -
6K 6K 6K 36K - - - 5,000 5,000 5,000 32,000 - - - 5,700 5,700 5,700 33,800 - - -
6K 6K 9K 18K - - - 6,000 6,000 9,000 18,000 - - - 6,400 6,400 9,600 19,100 - - -
6K 6K 9K 24K - - - 6,000 6,000 9,000 24,000 - - - 6,200 6,200 9,300 24,600 - - -
6K 6K 9K 30K - - - 6,000 6,000 8,000 28,000 - - - 5,900 5,900 8,800 29,200 - - -
6K 6K 9K 36K - - - 5,000 5,000 8,000 31,000 - - - 5,500 5,500 8,200 32,500 - - -
6K 6K 12K 12K - - - 6,000 6,000 12,000 12,000 - - - 6,500 6,500 12,900 12,900 - - -
6K 6K 12K 18K - - - 6,000 6,000 12,000 18,000 - - - 6,300 6,300 12,600 18,900 - - -
6K 6K 12K 24K - - - 6,000 6,000 11,000 23,000 - - - 6,100 6,100 12,100 24,100 - - -
6K 6K 12K 30K - - - 5,000 5,000 11,000 27,000 - - - 5,700 5,700 11,300 28,200 - - -
6K 6K 12K 36K - - - 5,000 5,000 10,000 30,000 - - - 5,200 5,200 10,400 31,000 - - -
6K 6K 18K 18K - - - 6,000 6,000 17,000 17,000 - - - 6,100 6,100 18,100 18,100 - - -
6K 6K 18K 24K - - - 5,000 5,000 16,000 22,000 - - - 5,700 5,700 16,900 22,600 - - -
6K 6K 18K 30K - - - 5,000 5,000 15,000 25,000 - - - 5,200 5,200 15,500 25,800 - - -
6K 6K 24K 24K - - - 5,000 5,000 20,000 20,000 - - - 5,200 5,200 20,700 20,700 - - -
6K 9K 9K 12K - - - 6,000 9,000 9,000 12,000 - - - 6,500 9,700 9,700 12,900 - - -
6K 9K 9K 18K - - - 6,000 9,000 9,000 18,000 - - - 6,300 9,500 9,500 18,900 - - -
6K 9K 9K 24K - - - 6,000 9,000 9,000 23,000 - - - 6,100 9,100 9,100 24,100 - - -
6K 9K 9K 30K - - - 5,000 8,000 8,000 27,000 - - - 5,700 8,500 8,500 28,200 - - -
6K 9K 9K 36K - - - 5,000 7,000 7,000 30,000 - - - 5,200 7,800 7,800 31,000 - - -
6K 9K 12K 12K - - - 6,000 9,000 12,000 12,000 - - - 6,400 9,600 12,800 12,800 - - -
6K 9K 12K 18K - - - 6,000 9,000 12,000 18,000 - - - 6,200 9,300 12,300 18,500 - - -
6K 9K 12K 24K - - - 6,000 8,000 11,000 22,000 - - - 5,900 8,800 11,700 23,400 - - -
6K 9K 12K 30K - - - 5,000 8,000 10,000 26,000 - - - 5,500 8,200 10,900 27,100 - - -
6K 9K 12K 36K - - - 5,000 7,000 9,000 28,000 - - - 4,900 7,400 9,800 29,300 - - -
6K 9K 18K 18K - - - 6,000 8,000 17,000 17,000 - - - 5,900 8,800 17,500 17,500 - - -
6K 9K 18K 24K - - - 5,000 8,000 16,000 21,000 - - - 5,500 8,200 16,300 21,700 - - -
6K 9K 18K 30K - - - 5,000 7,000 14,000 24,000 - - - 4,900 7,400 14,700 24,500 - - -
6K 12K 12K 12K - - - 6,000 12,000 12,000 12,000 - - - 6,300 12,600 12,600 12,600 - - -
