Lennox MMDB Service Manual

61
Table 5. MPC Multi-Zone System Combinations
NOTE - For multi-zone systems, the total capacity of all indoor units must be 66% to 133% of the outdoor unit capacity.
Outdoor Unit
Model No.
Number
of
Zones
Indoor Unit
Capacity
Nominal Cooling Capacity at Rated
System Capacity (Btuh)
Nominal Heating Capacity at Rated
System Capacity (Btuh)
#1 #2 #3 #4 #5 #1 #2 #3 #4 #5 #1 #2 #3 #4 #5
MPC048S4M 5
6K 6K 6K 18K 24K 5,000 5,000 5,000 16,000 21,000 5,000 5,000 5,000 16,000 21,000
6K 6K 9K 9K 9K 6,000 6,000 9,000 9,000 9,000 6,000 6,000 10,000 10,000 10,000
6K 6K 9K 9K 12K 6,000 6,000 9,000 9,000 12,000 6,000 6,000 9,000 9,000 13,000
6K 6K 9K 9K 18K 6,000 6,000 9,000 9,000 18,000 6,000 6,000 9,000 9,000 18,000
6K 6K 9K 9K 24K 6,000 6,000 8,000 8,000 22,000 5,000 5,000 8,000 8,000 23,000
6K 6K 9K 9K 30K 5,000 5,000 8,000 8,000 26,000 5,000 5,000 8,000 8,000 27,000
6K 6K 9K 12K 12K 6,000 6,000 9,000 12,000 12,000 6,000 6,000 9,000 12,000 12,000
6K 6K 9K 12K 18K 6,000 6,000 9,000 12,000 17,000 6,000 6,000 9,000 12,000 18,000
6K 6K 9K 12K 24K 5,000 5,000 8,000 11,000 22,000 5,000 5,000 8,000 11,000 22,000
6K 6K 9K 12K 30K 5,000 5,000 7,000 10,000 24,000 5,000 5,000 7,000 10,000 26,000
6K 6K 9K 18K 18K 5,000 5,000 8,000 16,000 16,000 5,000 5,000 8,000 17,000 17,000
6K 6K 9K 18K 24K 5,000 5,000 7,000 15,000 20,000 5,000 5,000 7,000 15,000 21,000
6K 6K 12K 12K 12K 6,000 6,000 12,000 12,000 12,000 6,000 6,000 12,000 12,000 12,000
6K 6K 12K 12K 18K 6,000 6,000 11,000 11,000 17,000 5,000 5,000 11,000 11,000 17,000
6K 6K 12K 12K 24K 5,000 5,000 10,000 10,000 21,000 5,000 5,000 10,000 10,000 21,000
6K 6K 12K 18K 18K 5,000 5,000 10,000 16,000 16,000 5,000 5,000 10,000 16,000 16,000
6K 9K 9K 9K 9K 6,000 9,000 9,000 9,000 9,000 6,000 9,000 9,000 9,000 9,000
6K 9K 9K 9K 12K 6,000 9,000 9,000 9,000 12,000 6,000 9,000 9,000 9,000 12,000
6K 9K 9K 9K 18K 6,000 9,000 9,000 9,000 17,000 6,000 9,000 9,000 9,000 18,000
6K 9K 9K 9K 24K 5,000 8,000 8,000 8,000 22,000 5,000 8,000 8,000 8,000 22,000
6K 9K 9K 9K 30K 5,000 7,000 7,000 7,000 24,000 5,000 7,000 7,000 7,000 26,000
6K 9K 9K 12K 12K 6,000 9,000 9,000 12,000 12,000 6,000 9,000 9,000 12,000 12,000
6K 9K 9K 12K 18K 6,000 8,000 8,000 11,000 17,000 5,000 8,000 8,000 11,000 17,000
6K 9K 9K 12K 24K 5,000 8,000 8,000 10,000 21,000 5,000 8,000 8,000 10,000 21,000
6K 9K 9K 18K 18K 5,000 8,000 8,000 16,000 16,000 5,000 8,000 8,000 16,000 16,000
6K 9K 12K 12K 12K 6,000 9,000 12,000 12,000 12,000 6,000 9,000 12,000 12,000 12,000
6K 9K 12K 12K 18K 5,000 8,000 11,000 11,000 16,000 5,000 8,000 11,000 11,000 17,000
6K 9K 12K 12K 24K 5,000 7,000 10,000 10,000 20,000 5,000 7,000 10,000 10,000 21,000
6K 12K 12K 12K 12K 6,000 11,000 11,000 11,000 11,000 5,000 11,000 11,000 11,000 11,000
6K 12K 12K 12K 18K 5,000 10,000 10,000 10,000 16,000 5,000 10,000 10,000 10,000 16,000
9K 9K 9K 9K 9K 9,000 9,000 9,000 9,000 9,000 9500 9500 9500 9500 9500
9K 9K 9K 9K 12K 9,000 9,000 9,000 9,000 12,000 9,000 9,000 9,000 9,000 12,000
9K 9K 9K 9K 18K 8,000 8,000 8,000 8,000 17,000 8,000 8,000 8,000 8,000 17,000
9K 9K 9K 9K 24K 8,000 8,000 8,000 8,000 21,000 8,000 8,000 8,000 8,000 21,000
9K 9K 9K 12K 12K 9,000 9,000 9,000 12,000 12,000 9,000 9,000 9,000 12,000 12,000
9K 9K 9K 12K 18K 8,000 8,000 8,000 11,000 16,000 8,000 8,000 8,000 11,000 17,000
9K 9K 9K 12K 24K 7,000 7,000 7,000 10,000 20,000 7,000 7,000 7,000 10,000 21,000
9K 9K 12K 12K 12K 8,000 8,000 11,000 11,000 11,000 8,000 8,000 11,000 11,000 11,000
9K 9K 12K 12K 18K 8,000 8,000 10,000 10,000 16,000 8,000 8,000 10,000 10,000 16,000
9K 12K 12K 12K 12K 8,000 11,000 11,000 11,000 11,000 8,000 11,000 11,000 11,000 11,000
12K 12K 12K 12K 12K 10,000 10,000 10,000 10,000 10,000 10,000 10,000 10,000 10,000 10,000
