Lennox MPC User Manual

80
Table 12. MLB030S4M
Number of Zones and Outdoor Unit Connection Sizes
NOTE - Letter = Indoor Unit Zone Connection on Outdoor Unit
Zone 1 (A) Zone 2 (B) Zone 3 (C)
1/4 in. liq + 3/8 in. gas 1/4 in. liq + 3/8 in. gas 1/4 in. liq + 3/8 in. gas
012 012 012
LEGEND:
CLEAR = No adapters required.
GRAY = 3/8 x 1/2 in. gas pipe adapter is required for line set connection to outdoor unit (furnished with outdoor unit).
Table 13. MLB036S4M
Number of Zones and Outdoor Unit Connection Sizes
NOTE - Letter = Indoor Unit Zone Connection on Outdoor Unit
Zone 1 (A) Zone 2 (B) Zone 3 (C) Zone 4 (D)
1/4 in. liq + 1/2 in. gas 1/4 in. liq + 3/8 in. gas 1/4 in. liq + 3/8 in. gas 1/4 in. liq + 3/8 in. gas
009 018 - - - - - -
009 024 - - - - - -
009 030 - - - - - -
012 012 - - - - - -
012 018 - - - - - -
012 024 - - - - - -
012 030 - - - - - -
018 018 - - - - - -
018 024 - - - - - -
018 030 - - - - - -
024 024 - - - - - -
009 009 009 - - -
009 009 012 - - -
009 009 018 - - -
009 009 024 - - -
009 009 030 - - -
009 012 012 - - -
009 012 018 - - -
009 012 024 - - -
009 018 018 - - -
012 012 012 - - -
012 012 018 - - -
012 012 024 - - -
012 018 018 - - -
009 009 009 009
009 009 009 012
009 009 009 018
009 009 012 012
009 009 012 018
009 012 012 012
012 012 012 012
LEGEND:
CLEAR = No adapters required.
GRAY = 3/8 x 1/2 in. gas pipe adapter is required for line set connection to outdoor unit (furnished with outdoor unit).
BLACK = 1/4 x 3/8 in. liquid pipe adapter is required for line set connection to the 036 outdoor unit (furnished with outdoor unit).
1/2 x 5/8 in. gas pipe adapter is required for line set connection to the 036 outdoor unit (furnished with outdoor unit).
