Lennox MPC User Manual

81
Table 14. MLB048S4M
Number of Zones and Outdoor Unit Connection Sizes
NOTE - Letter = Indoor Unit Zone Connection on Outdoor Unit
Zone 1 (A) Zone 2 (B) Zone 3 (C) Zone 4 (D) Zone 5 (E)
1/4 in. liq + 1/2 in. gas 1/4 in. liq + 1/2 in. gas 1/4 in. liq + 3/8 in. gas 1/4 in. liq + 3/8 in. gas 1/4 in. liq + 3/8 in. gas
009 030 - - - - - - - - -
009 036 - - - - - - - - -
012 024 - - - - - - - - -
012 030 - - - - - - - - -
012 036 - - - - - - - - -
018 018 - - - - - - - - -
018 024 - - - - - - - - -
018 030 - - - - - - - - -
018 036 - - - - - - - - -
024 030 - - - - - - - - -
024 036 - - - - - - - - -
030 030 - - - - - - - - -
009 009 018 - - - - - -
009 009 024 - - - - - -
009 009 030 - - - - - -
009 009 036 - - - - - -
009 012 012 - - - - - -
009 012 018 - - - - - -
009 012 024 - - - - - -
009 012 030 - - - - - -
009 012 036 - - - - - -
009 018 018 - - - - - -
009 018 024 - - - - - -
009 018 030 - - - - - -
009 018 036 - - - - - -
009 024 024 - - - - - -
009 024 030 - - - - - -
012 012 012 - - - - - -
012 012 018 - - - - - -
012 012 024 - - - - - -
012 012 030 - - - - - -
012 012 036 - - - - - -
012 018 018 - - - - - -
012 018 024 - - - - - -
012 018 030 - - - - - -
012 024 024 - - - - - -
018 018 018 - - - - - -
018 018 024 - - - - - -
009 009 009 009 - - -
009 009 009 012 - - -
LEGEND:
CLEAR = No adapters required.
GRAY = 3/8 x 1/2 in. gas pipe adapter is required for line set connection to outdoor unit (furnished with outdoor unit).
BLACK = 1/4 x 3/8 in. liquid pipe adapter is required for line set connection to the 048 outdoor unit (furnished with outdoor unit).
1/2 x 5/8 in. gas pipe adapter is required for line set connection to the 048 outdoor unit (furnished with outdoor unit).
