FURNACE BLOWER SPECIFICATIONS AND AIR FLOW DATA
BLOWER
SYSTEM
BLOWER
SPEED
EXTERNAL STATIC (IN. W.C.)
0.1 0.2 0.3 0.4 0.5 0.6 0.7 0.8 0.9 1.0
MPGA050B3
(10X6 WHEEL)
(1/3HP MOTOR)
MPGA075B3
(10X6 WHEEL)
(1/3HP MOTOR)
MPGA075B4
(12X9 WHEEL)
(1 HP MOTOR)
MPGA100B4
(10X9 WHEEL)
(1 HP MOTOR)
MPGA100B5
(12X9 WHEEL)
(1 HP MOTOR)
MPGA125B5
(12X12 WHEEL)
(1 HP MOTOR)
NOTES:
1. Air flow values in cubic feet per minute (CFM).
2. Data taken without filters in place or A/C evaporator in place.
When operating the furnace in the heating mode, the static pressure and the temperature rise (supply air temperature
minus return air temperature) must be within those limits specified on the rating label. Failure to follow this warning
could lead to severe furnace damage.
Turn OFF all gas and electrical power to furnace before performing any maintenance or service on unit. (Unless
specific test requires gas and electrical supplies.) Failure to take this precaution may result in personal injury due
to electrical shock or uncontrolled gas leakage.
20541501 Issue 0240 Page 4 of 26
