Lennox MWHA018S4-1P Installation Instructions

3
WARNING
The clean Air Act of 1990 bans the intentional venting of
refrigerant (CFCs, HCFCs, and HFCs) as of July, 1992.
Approved methods of recovery, recycling or reclaiming
must be followed. Fines and/or incarceration may be
levied for non-compliance.
CAUTION
As with any mechanical equipment, contact with sharp
sheet metal edges can result in personal injury. Take
care while handling this equipment and wear gloves
and protective clothing.
IMPORTANT
All illustrations in this instruction are typical and do
not always represent the exact appearance of the
equipment.
IMPORTANT
The compressor in this unit contains PVE
oil (Polyvinylether). PVE oil is formulated for
hydrouorocarbon (HFC) refrigerants, such as HFC-
410A, which this system contains. While it may have
some miscibility properties with mineral-based oil and
POE oil (Polyolester), it is not recommended to mix PVE
oil with any other type of refrigerant oil.
Model Number Identication
M WH A 009 S 4 - 1 P
Unit Type
WH = Wall-Mounted Non-Ducted Unit
Series Type
M = Mini-Split
Voltage
L = 115V-1 phase-60Hz
P = 208/230V-1 phase-60Hz
WALL-MOUNTED INDOOR UNITS
Cooling Efciency
S = Standard Efciency
Major Design Sequence
A = First Generation
Nominal Cooling Capacity
009 = 0.75 ton
012 = 1 ton
018 = 1.5 tons
024 = 2 tons
Refrigerant Type
4 = HFC-410A
Minor Design Sequence
1 = 1st Revision
M H A 009 S 4 S - 1 P
Series Type
M = Mini-Split
OUTDOOR SINGLE ZONE HEAT PUMP UNITS
Cooling Efciency
S = Standard Efciency
Major Design Sequence
A = First Generation
Nominal Cooling Capacity
009 = 0.75 ton
012 = 1 ton
018 = 1.5 tons
024 = 2 tons
Refrigerant Type
4 = HFC-410A
Refrigerant Circuits
S = Single Circuit
Minor Design Sequence
1 = 1st Revision
Voltage
L = 115V-1 phase-60Hz
P = 208/230V-1 phase-60Hz
Unit Type
H = Heat Pump
