2.3. M33AandM33BIndoorUnitSpecications
Model No. M33A024S4-*P M33A036S4-*P M33A048S4-*P** and
M33B048S4-*P
NominalTons 2 3 4
PowerSupply-60hz-1phase 208/230V 208/230V 208/230V
Ratedloadamps 2.0 1.5 1.6
Output(W) 42 124 170
RoomTemperature
Range(°F)
Cooling 62 - 90 62 - 90 62 - 90
Heating 32 - 86 32 - 86 32 - 86
AirVolume-cfm(High/Medium/Low) 700/635/575 1095/960/810 1175/1030/855
SoundData(dBA)-Low/Medium/High 43/47/51 49/52/55 49/52/55
PipingConnections-Liquid/Gas-o.d.-are-in. 3/8 / 5/8 3/8 / 5/8 3/8 / 5/8
Drainconnectiono.d.-in. 1-1/4 1-1/4 1-1/4
Net/Shippingweights-lbs. Body 47/55 58 / 66 64/73
REQUIRED COMPONENTS - ORDERED SEPARATELY
Cassette Panel 13X05(M0STAT63Q-1) 13X05(M0STAT63Q-1) 13X05(M0STAT63Q-1)
Net/Shippingweights-lbs. 12 / 18 12 / 18 12 / 18
**MPAonly
