BLOWER DATA
SLP99UH110XV60C BLOWER PERFORMANCE (less lter)
SINGLE SIDE RETURN AIR − Air volumes in bold require Optional Return Air Base and eld fabricated transition to accommodate
20 x 25 x 1 in. air lter in order to maintain proper air velocity.
HEATING BLOWER PERFORMANCE - 0 through 0.8 in. w.g. External Static Pressure Range
Heating Adjust CFM Selections
Heating Input Range and Blower Volume - CFM
35% 40% 50% 60% 70% 80% 90% 100%
Increase (+15%) Heat CFM 733 825 1009 1194 1378 1562 1747 1931
Increase (+7.5%) Heat CFM 708 794 967 1139 1312 1484 1657 1829
Default Heat CFM 683 763 924 1085 1245 1406 1566 1727
Decrease (-7.5% ) Heat CFM 632 707 857 1007 1157 1307 1457 1608
Decrease (-15% ) Heat CFM 580 650 790 929 1069 1209 1348 1488
COOLING BLOWER PERFORMANCE - 0 through 1.0 in. w.g. External Static Pressure Range
Cooling Adjust CFM
Selections
Blower Speed Selections
First Stage Cool Speed - cfm Second Stage Cool Speed - cfm
Low Medium-
Low
Medium
High
High
(Default)
Low Medium-
Low
Medium
High
High
(Default)
Increase (+10%) Cool CFM 1050 1195 1315 1495 1515 1710 1870 2065
Default Cool CFM 960 1095 1220 1355 1360 1555 1755 1890
Decrease (-10%) Cool CFM 850 985 1095 1220 1215 1400 1555 1755
The e󰀨ect of static pressure is included in air volumes shown.
The following control congurations are available. See Installation Instructions for details and DIP switch settings.
Heat Modes Available (Heating Blower Performance Table):
Single stage thermostat:
- 35%, 70%, 100% input (three-stage) with time delays in-between.
Two-stage thermostat:
- Variable Rate Capacity Mode - furnace automatically adjusts ring rate based on rst- and second-stage cycle times.
- W1 demand at 70% input, W2 demand at 100% input. No delay between stages.
Cool Mode Available (Cooling Blower Performance table):
First stage COOL (two-stage air conditioning units only) is approximately 70% of the same second stage COOL speed position.
Continuous Fan speeds are approximately 28% and 38% (DIP switch selectable) of the same second-stage COOL speed position.
minimum 380 cfm.
Lennox iHarmony
®
Zoning System Applications - Minimum blower speed is 450 cfm.
