Lennox TPA036H4 User Manual

TP − 3 to 5 Ton High−Efficiency, R−410A Heat Pump / Page 11
ARI RATINGS
1
ARI Standard 210/240 Ratings
Capacity − Btuh Efficiency Total Watts COP
Id UitMdlN
Expansion
Cooling
High
Temp
Low
Temp
HSPF
Cool
Hi
g
h Low Hi
g
h Low
Indoor Unit Model No.
Expansion
Device
C
oo
li
ng
Temp.
Heating
Temp.
Heating
SEER EER IV V
C
oo
l
High
Heat
Low
Heat
High
Heat
Low
Heat
TPA036H4 3 TON
Down−Flow Indoor Coils Down−Flow Coils
33,800 35,200 21,400 13.00 11.00 7.70 6.70 3075 2980 2730 3.46 2.30
3
CR33−48B/C−F
2
49L25
34,800 35,600 21,600 13.00 11.00 7.70 6.70 3165 2875 2655 3.62 2.38
3
CR33−50/60C−F
2
49L25
Down−Flow Indoor Coils + Furnaces Down−Flow Coils + Furnaces
34,200 34,800 21,000 14.00 12.00 8.20 7.00 2850 2860 2605 3.56 2.36 CR33−48B−F
4
G61MPV−36B−045
2
49L25
34,200 34,800 21,000 14.00 12.00 8.20 7.00 2850 2855 2600 3.58 2.36 CR33−48B−F
4
G61MPV−36B−070
2
49L25
34,200 34,800 21,000 14.00 12.00 8.20 7.00 2850 2855 2600 3.58 2.36 CR33−48B−F
4
G71MPP−36B−070
2
49L25
34,200 34,800 21,000 14.00 12.00 8.20 7.00 2850 2855 2600 3.58 2.36 CR33−48B−F
4
G61MPV−36B−071
2
49L25
34,400 34,600 20,800 14.50 12.00 8.20 7.00 2865 2780 2525 3.64 2.42 CR33−48C−F
4
G61MPV−36C−090
2
49L25
34,400 34,600 20,800 14.50 12.00 8.20 7.00 2865 2780 2525 3.64 2.42 CR33−48C−F
4
G71MPP−36C−090
2
49L25
34,400 34,600 20,800 14.50 12.50 8.20 7.00 2750 2765 2515 3.66 2.42 CR33−48B−F
4
G60DFV−36B−090
2
49L25
34,600 34,800 21,000 14.50 12.00 8.20 7.20 2885 2770 2535 3.68 2.42 CR33−48C−F
4
G61MPV−60C−090
2
49L25
34,600 34,800 21,000 14.50 12.00 8.20 7.20 2885 2770 2535 3.68 2.42 CR33−48C−F
4
G71MPP−60C−090
2
49L25
35,600 34,600 20,600 15.00 13.00 9.00 7.50 2850 2545 2330 3.98 2.58 CR33−50/60C−F
4
G61MPV−36C−090
2
49L25
35,600 34,600 20,600 15.00 13.00 9.00 7.50 2850 2545 2330 3.98 2.58 CR33−50/60C−F
4
G71MPP−36C−090
2
49L25
36,000 35,000 20,800 15.00 13.00 9.00 7.50 2880 2545 2340 4.04 2.60 CR33−50/60C−F
4
G61MPV−60C−090
2
49L25
36,000 35,000 20,800 15.00 13.00 9.00 7.50 2880 2545 2340 4.04 2.60 CR33−50/60C−F
4
G71MPP−60C−090
2
49L25
Horizontal Indoor Coils Horizontal Coils
35,000 35,200 21,400 13.00 11.00 7.70 6.70 3180 3015 2795 3.42 2.24
3
CH33−44/48B−2F
2
49L25
35,200 35,000 21,200 13.00 11.00 7.70 6.70 3200 3050 2815 3.36 2.20
3
CH33−43C−2F
2
49L25
35,400 35,200 21,400 13.00 11.00 7.70 6.70 3220 3020 2800 3.42 2.24
3
CH33−50/60C−2F
2
49L25
35,600 35,200 21,400 13.00 11.00 7.70 6.70 3235 2995 2770 3.44 2.26
3
CH33−43B−2F
2
49L25
35,600 35,200 21,400 13.00 11.00 7.70 6.70 3235 3020 2800 3.42 2.24
3
CH33−49C−2F
2
49L25
Horizontal Indoor Coils + Furnaces Horizontal Coils + Furnaces
35,200 34,800 21,000 14.00 12.00 8.20 6.70 2935 2930 2705 3.48 2.28 CH33−44/48B−2F
4
G61MPV−36B−045
2
49L25
35,200 34,800 21,000 14.00 12.00 8.20 6.70 2935 2920 2700 3.50 2.28 CH33−44/48B−2F
4
G61MPV−36B−070
2
49L25
35,200 34,800 21,000 14.00 12.00 8.20 6.70 2935 2920 2700 3.50 2.28 CH33−44/48B−2F
4
G71MPP−36B−070
2
49L25
35,200 34,800 21,000 14.00 12.00 8.20 6.70 2935 2920 2700 3.50 2.28 CH33−44/48B−2F
4
G61MPV−36B−071
2
49L25
35,400 34,600 20,800 15.00 12.50 8.20 7.00 2830 2835 2625 3.58 2.32 CH33−44/48B−2F
4
G60UHV−36B−090
2
49L25
35,600 34,600 20,800 14.50 12.50 8.00 6.70 2850 2925 2685 3.46 2.26 CH33−43C−2F
4
G61MPV−36B−071
2
49L25
35,800 35,000 21,200 14.50 12.00 8.20 6.70 2985 2910 2680 3.52 2.32 CH33−43B−2F
4
G61MPV−36B−045
2
49L25
36,000 34,400 20,600 15.00 12.50 8.20 7.00 2880 2820 2595 3.58 2.32 CH33−50/60C−2F
4
G61MPV−36C−090
2
49L25
36,000 34,400 20,600 15.00 12.50 8.20 7.00 2880 2820 2595 3.58 2.32 CH33−50/60C−2F
4
G71MPP−36C−090
2
49L25
36,000 34,600 20,600 15.00 12.50 8.20 7.00 2880 2820 2600 3.60 2.32 CH33−49C−2F
4
G61MPV−36C−090
2
49L25
36,000 34,600 20,600 15.00 12.50 8.20 7.00 2880 2820 2600 3.60 2.32 CH33−49C−2F
4
G71MPP−36C−090
2
49L25
36,000 35,000 21,000 14.50 12.50 8.20 7.00 2880 2900 2670 3.54 2.30 CH33−43B−2F
4
G61MPV−36B−070
2
49L25
36,000 35,000 21,000 14.50 12.50 8.20 7.00 2880 2900 2670 3.54 2.30 CH33−43B−2F
4
G71MPP−36B−070
2
49L25
36,200 34,800 20,800 15.00 12.50 8.20 7.00 2895 2805 2600 3.64 2.34 CH33−50/60C−2F
4
G61MPV−60C−090
2
49L25
36,200 34,800 20,800 15.00 12.50 8.20 7.00 2895 2805 2600 3.64 2.34 CH33−50/60C−2F
4
G71MPP−60C−090
2
49L25
36,200 34,800 21,000 15.00 12.50 8.20 7.00 2895 2815 2595 3.62 2.36 CH33−43B−2F
4
G60UHV−36B−090
2
49L25
36,400 34,800 20,800 15.00 12.50 8.20 7.00 2910 2800 2600 3.64 2.34 CH33−49C−2F
4
G61MPV−60C−090
2
49L25
36,400 34,800 20,800 15.00 12.50 8.20 7.00 2910 2800 2600 3.64 2.34 CH33−49C−2F
4
G71MPP−60C−090
2
49L25
NOTE − When used with gas furnaces, a dual−fuel control (i.e. FM21) or a control system with dual−fuel capabilities (i.e. Harmony III, LZP−2 or LZP−4) must be used (ordered extra).
1
Certified in accordance with USE certification program which is based on ARI Standard 210/240 with 25 ft. of connecting refrigerant lines;
Cooling Ratings − 95_F outdoor air temperature and 80_F db/67_F wb entering indoor coil air.
High Temperature Heating Ratings − 47_F db/43_F wb outdoor air temperature and 70_F db entering indoor coil air.
Low Temperature Heating Ratings − 17_F db/15_F wb outdoor air temperature and 70_F db entering indoor coil air.
2
Factory installed expansion valve or RFC on indoor unit MUST be replaced with valve specified (if equipped).
3
Blower must be capable of time−off blower delay. Indoor Blower Off Delay Relay (58M81) is recommend for field installation.
4
Blower control must be set for a time−off blower delay.
