TP − 3 to 5 Ton High−Efficiency, R−410A Heat Pump / Page 10
ARI RATINGS
1
ARI Standard 210/240 Ratings
Capacity − Btuh Efficiency Total Watts COP
Id UitMdlN
Expansion
Cooling
High
Temp
Low
Temp
HSPF
Cool
Hi
g
h Low Hi
g
h Low
Indoor Unit Model No.
Expansion
Device
C
oo
li
ng
Temp.
Heating
Temp.
Heating
SEER EER IV V
C
oo
l
High
Heat
Low
Heat
High
Heat
Low
Heat
TPA036H4 3 TON
Up−Flow Indoor Coils + Furnaces Up−Flow Coils + Furnaces
34,600 35,000 21,200 14.00 12.00 8.20 7.20 2885 2825 2575 3.64 2.42 CX34−38B−6F
4
G61MPV−36B−070
2
49L25
34,600 35,000 21,200 14.00 12.00 8.20 7.20 2885 2825 2575 3.64 2.42 CX34−38B−6F
4
G71MPP−36B−070
2
49L25
34,600 35,000 21,200 14.00 12.00 8.20 7.20 2885 2825 2575 3.64 2.42 CX34−38B−6F
4
G61MPV−36B−071
2
49L25
34,800 34,400 20,800 14.00 12.00 7.70 6.70 2900 3010 2735 3.34 2.22 CX34−44/48B−6F
4
G61MPV−36B−045 Factory TXV
34,800 35,200 21,200 14.00 12.00 8.20 7.20 2900 2835 2595 3.64 2.40 CX34−38A−6F
4
G60UHV−36A−070
2
49L25
34,800 35,200 21,400 14.00 12.00 8.20 7.20 2900 2850 2610 3.62 2.40 CX34−38B−6F
4
G61MPV−36B−045
2
49L25
35,000 34,200 20,600 15.00 12.50 8.00 6.70 2800 2930 2655 3.42 2.28 CX34−44/48C−6F
4
G61MPV−36C−090 Factory TXV
35,000 34,200 20,600 15.00 12.50 8.00 6.70 2800 2930 2655 3.42 2.28 CX34−44/48C−6F
4
G71MPP−36C−090 Factory TXV
35,000 34,400 20,800 14.50 12.00 8.00 6.70 2915 3005 2725 3.36 2.24 CX34−44/48B−6F
4
G61MPV−36B−070 Factory TXV
35,000 34,400 20,800 14.50 12.00 8.00 6.70 2915 3005 2725 3.36 2.24 CX34−44/48B−6F
4
G71MPP−36B−070 Factory TXV
35,000 34,400 20,800 14.50 12.00 8.00 6.70 2915 3005 2725 3.36 2.24 CX34−44/48B−6F
4
G61MPV−36B−071 Factory TXV
35,000 34,800 21,000 15.00 12.50 8.50 7.20 2800 2735 2495 3.72 2.46 CX34−38B−6F
4
G60UHV−36B−090
2
49L25
35,200 34,000 20,400 15.00 12.50 8.00 6.70 2815 2875 2595 3.46 2.30 CX34−43B−6F
4
G60UHV−36B−090 Factory TXV
35,200 34,200 20,600 15.00 12.50 8.00 6.70 2815 2910 2645 3.44 2.28 CX34−44/48B−6F
4
G60UHV−36B−090 Factory TXV
35,400 34,400 20,600 15.00 12.50 8.20 6.70 2830 2865 2620 3.52 2.30 CX34−50/60C−6F
4
G61MPV−36C−090 Factory TXV
35,400 34,400 20,600 15.00 12.50 8.20 6.70 2830 2865 2620 3.52 2.30 CX34−50/60C−6F
4
G71MPP−36C−090 Factory TXV
35,400 34,400 20,800 15.00 12.50 8.00 6.70 2830 2910 2655 3.46 2.30 CX34−44/48C−6F
4
G61MPV−60C−090 Factory TXV
35,400 34,400 20,800 15.00 12.50 8.00 6.70 2830 2910 2655 3.46 2.30 CX34−44/48C−6F
4
G71MPP−60C−090 Factory TXV
35,400 34,600 20,800 14.50 12.50 8.00 6.70 2830 2935 2695 3.46 2.26 CX34−43B−6F
4
G61MPV−36B−045 Factory TXV
35,400 34,600 20,800 14.50 12.50 8.00 6.70 2830 2925 2685 3.46 2.26 CX34−43B−6F
4
G61MPV−36B−070 Factory TXV
35,400 34,600 20,800 14.50 12.50 8.00 6.70 2830 2925 2685 3.46 2.26 CX34−43B−6F
4
G71MPP−36B−070 Factory TXV
35,400 34,600 20,800 14.50 12.50 8.00 6.70 2830 2925 2685 3.46 2.26 CX34−43B−6F
4
G61MPV−36B−071 Factory TXV
35,600 34,400 20,600 15.00 12.50 8.00 6.70 2850 2855 2610 3.54 2.32 CX34−43C−6F
4
G61MPV−36C−090 Factory TXV
35,600 34,400 20,600 15.00 12.50 8.00 6.70 2850 2855 2610 3.54 2.32 CX34−43C−6F
4
G71MPP−36C−090 Factory TXV
35,800 34,600 20,800 15.00 12.50 8.00 7.00 2865 2845 2620 3.56 2.32 CX34−50/60C−6F
4
G61MPV−60C−090
2
49L25
35,800 34,600 20,800 15.00 12.50 8.00 7.00 2865 2845 2620 3.56 2.32 CX34−50/60C−6F
4
G71MPP−60C−090
2
49L25
36,000 34,400 20,600 15.00 12.50 8.20 7.00 2880 2845 2605 3.54 2.32 CX34−49C−6F
4
G61MPV−36C−090
2
49L25
36,000 34,400 20,600 15.00 12.50 8.20 7.00 2880 2845 2605 3.54 2.32 CX34−49C−6F
4
G71MPP−36C−090
2
49L25
36,000 34,600 20,800 15.00 12.50 8.20 7.00 2880 2845 2615 3.56 2.32 CX34−43C−6F
4
G61MPV−60C−090 Factory TXV
36,000 34,600 20,800 15.00 12.50 8.20 7.00 2880 2845 2615 3.56 2.32 CX34−43C−6F
4
G71MPP−60C−090 Factory TXV
36,400 34,600 20,800 15.00 12.50 8.20 7.00 2910 2825 2610 3.58 2.34 CX34−49C−6F
4
G61MPV−60C−090
2
49L25
36,400 34,600 20,800 15.00 12.50 8.20 7.00 2910 2825 2610 3.58 2.34 CX34−49C−6F
4
G71MPP−60C−090
2
49L25
NOTE − When used with gas furnaces, a dual−fuel control (i.e. FM21) or a control system with dual−fuel capabilities (i.e. Harmony III, LZP−2 or LZP−4) must be used (ordered extra).
1
Certified in accordance with USE certification program which is based on ARI Standard 210/240 with 25 ft. of connecting refrigerant lines;
Cooling Ratings − 95_F outdoor air temperature and 80_F db/67_F wb entering indoor coil air.
High Temperature Heating Ratings − 47_F db/43_F wb outdoor air temperature and 70_F db entering indoor coil air.
Low Temperature Heating Ratings − 17_F db/15_F wb outdoor air temperature and 70_F db entering indoor coil air.
2
Factory installed expansion valve or RFC on indoor unit MUST be replaced with valve specified (if equipped).
3
Blower must be capable of time−off blower delay. Indoor Blower Off Delay Relay (58M81) is recommend for field installation.
4
Blower control must be set for a time−off blower delay.
