TP − 3 to 5 Ton High−Efficiency, R−410A Heat Pump / Page 9
ARI RATINGS − INDOOR COIL / AIR HANDLER SUBSTITUTION
Substituting Coils in the ARI Tables
Most R−22 and R−410A indoor coils and air handlers are the same except for the factory installed expansion device. C33
coils can be used in place of the CX34 coils, CB26UH, CB27UH and CB30M air handlers can be used in place of the
CBX26UH, CBX27UH and CBX32M, respectively.
The expansion device is based on the size of the outdoor unit. The factory installed RFC or TXV on the
C33/CB26UH/CB27UH/CB30M must be replaced to correspond to the outdoor unit. The correct TXV’s are:
3−3.5 ton heat pumps 49L25
4−5 ton heat pumps 91M02
Example:
A four−ton heat pump is being installed. The ARI table shows that CBX32M−048 is a matching air handler. A CB30M−51 with
a 91M02 TXV can be used in its place.
UP−FLOW COILS
R−410A R−22
CX34−31A−6F
=
C33−31A−2
CX34−31B−6F
=
C33−31B−2
CX34−36A−6F
=
C33−36A−2
CX34−36B−6F
=
C33−36B−2
CX34−36C−6F
=
C33−36C−2
CX34−38A−6F
=
C33−38A−2
CX34−38B−6F
=
C33−38B−2
CX34−42B−6F = C33−42B−2
CX34−43B−6F = C33−43B−2
CX34−43C−6F = C33−43C−2
no equivalent
C33−44C−2
CX34−44/48B−6F
=
C33−48B−2
CX34−44/48C−6F
=
C33−48C−2
CX34−49C−6F
=
C33−49C−2
CX34−50/60C−6F
=
C33−50/60C−2
CX34−60D−6F
=
C33−60D−2
CX34−62C−6F
=
C33−62C−2
CX34−62D−6F
=
C33−62D−2
AIR HANDLERS
R−410A R−22
CBX26UH−036
= CB26UH−036−R
CBX26UH−042 = CB26UH042−R
CBX26UH−048 = CB26UH−048
CBX26UH−060
= CB26UH−060−R
CBX27UH−036 = CB27UH−036
CBX27UH−042 = CB27UH−042
CBX27UH−048
= CB27UH−048
CBX27UH−060 = CB27UH−060
CBX32M−036 = CB30M−41
CBX32M−042
= CB30M−46
CBX32M−048 = CB30M−51
CBX32M−060 = CB30M−65
CBX32MV all
no equivalent
ARI RATINGS
1
ARI Standard 210/240 Ratings
Capacity − Btuh Efficiency Total Watts COP
Id UitMdlN
Expansion
Cooling
High
Temp
Low
Temp
HSPF
Cool
Hi
g
h Low Hi
g
h Low
Indoor Unit Model No.
Expansion
Device
C
oo
li
ng
Temp.
Heating
Temp.
Heating
SEER EER IV V
C
oo
l
High
Heat
Low
Heat
High
Heat
Low
Heat
TPA036H4 3 TON
Air Handlers Air Handlers
34,400 35,400 21,400 14.00 12.00 8.20 7.20 2865 2790 2570 3.72 2.44
4
CBX32M−042 (Multi−Position)
2
49L25
34,400 35,600 21,400 14.00 12.00 8.20 7.20 2865 2785 2575 3.74 2.44
4
CBX32M−036 (Multi−Position) Factory TXV
34,600 35,200 21,400 14.00 12.00 8.20 7.20 2885 2830 2595 3.64 2.42
5
CBX26UH−037 (Up−Flow / Horizontal) Factory TXV
34,600 35,400 21,400 14.00 12.00 8.20 7.20 2885 2760 2550 3.76 2.46
4
CBX32MV−036 (Multi−Position) Factory TXV
34,800 35,000 21,000 15.00 12.50 8.50 7.20 2785 2670 2450 3.84 2.50
4
CBX27UH−036 (Up−Flow / Horizontal) Factory TXV
35,800 35,200 21,200 15.00 12.50 8.50 7.20 2865 2685 2485 3.84 2.50
4
CBX32MV−048 (Multi−Position)
2
49L25
Up−Flow Indoor Coils Up−Flow Coils
34,400 35,400 21,600 13.00 11.00 7.70 6.70 3125 2950 2705 3.52 2.34
3
CX34−38A/B−6F
2
49L25
34,600 34,800 21,200 13.00 11.00 7.70 6.70 3145 3130 2855 3.26 2.18
3
CX34−44/48B/C−6F Factory TXV
35,000 35,000 21,200 13.00 11.00 7.70 6.70 3180 3065 2820 3.34 2.20
3
CX34−50/60C−6F
2
49L25
35,200 35,000 21,200 13.00 11.00 7.70 6.70 3200 3055 2815 3.36 2.20
3
CX34−43B/C−6F Factory TXV
35,400 35,000 21,200 13.00 11.00 7.70 6.70 3220 3045 2805 3.36 2.22
3
CX34−49C−6F
2
49L25
NOTE − When used with gas furnaces, a dual−fuel control (i.e. FM21) or a control system with dual−fuel capabilities (i.e. Harmony III, LZP−2 or LZP−4) must be used (ordered extra).
1
Certified in accordance with USE certification program which is based on ARI Standard 210/240 with 25 ft. of connecting refrigerant lines;
Cooling Ratings − 95_F outdoor air temperature and 80_F db/67_F wb entering indoor coil air.
High Temperature Heating Ratings − 47_F db/43_F wb outdoor air temperature and 70_F db entering indoor coil air.
Low Temperature Heating Ratings − 17_F db/15_F wb outdoor air temperature and 70_F db entering indoor coil air.
2
Factory installed expansion valve or RFC on indoor unit MUST be replaced with valve specified (if equipped).
3
Blower must be capable of time−off blower delay. Indoor Blower Off Delay Relay (58M81) is recommend for field installation.
4
Blower control must be set for a time−off blower delay.
5
Most popular air handler combination.
