Lennox TPA036H4 User Manual

TP − 3 to 5 Ton High−Efficiency, R−410A Heat Pump / Page 6
SPECIFICATIONS
General
Dt
Model No. TPA036H4 TPA042H4 TPA048H4 TPA060H4
Data
Nominal Tonnage 3
3.5 4 5
1
Sound Rating Number 79 79 80 80
Connections
(sweat)
Liquid line o.d. − in. 3/8 3/8 3/8 3/8
(sweat)
Vapor line o.d. − in. 7/8
7/8 7/8 1-1/8
2
Refrigerant R−410A charge furnished 9 lbs. 12 oz. 12 lbs. 7 oz. 12 lbs. 10 oz. 16 lbs. 0 oz.
Outdoor
Coil
Net face area
sq ft
Outer coil 19.39 24.93 24.93 29.09
Coil sq. ft.
Inner coil 18.77
24.13 24.13 28.16
Tube diameter − in. 5/16 5/16 5/16 5/16
No. of rows 2 2 2 2
Fins per inch 22 22 22 22
Outdoor
Fan
Diameter − in. 26 26 26 26
Fan
No. of Blades 4
4 4 4
Motor hp 1/3 1/3 1/3 1/3
Cfm 4090 4347 4347 4550
Rpm 844 843 843 830
Watts 299 299 299 307
Shipping Data − lbs. 1 package 212 257 262 307
ELECTRICAL DATA
Line voltage data − 60 hz − 1ph 208/230V 460V 208/230V 460V 208/230V 460V 208/230V 460V
3
Maximum overcurrent protection (amps) 20 15 30 15 30 15 35 15
4
Minimum circuit ampacity 13.1 8.1 18.6 8.4 18.9 8.7 21.8 10.7
Compressor
Rated Load Amps
9.6 5.6 13.5 6.0 13.7 6.2 16.0 7.8
p
Locked Rotor Amps
71
38 88 44 83.1 41. 110 52
Power Factor
.85
.84 .83 .81 .90 .92 .90 .91
Outdoor
Fan Motor
Full Load Amps
1.8 1.0 1.8 1.0 1.8 1.0 1.8 1.0
Fan Motor
Locked Rotor Amps
2.9
2.5 2.9 2.5 2.9 2.5 2.9 2.5
OPTIONAL ACCESSORIES − must be ordered extra
Compressor Sound Cover 69J03 S S S S
Freezestat
3/8 in. tubing 93G35 S S S S
5/8 in. tubing 50A93 S S S S
Hail Guards
27W34 S
27W36 S S
94M94 S
Indoor Blower Off Delay Relay 58M81 S S S S
Loss of Charge Kit 84M23 S S S S
Low Ambient Control Options − See table page 7 S S S S
Mild Weather Kit 33M07 S S S S
Monitor Kit − Service Light 76F53 S S S S
Mounting Base 69J07 S S S S
Outdoor
Th t t Kit
Thermostat 56A87 S S S S
Thermostat Kit
Mounting Box 31461 S
S S
Refrigerant
Line Sets
L15−65−30 L15−65−40
L15−65−50
S S S
Field Fabricate S
Unit Stand−Off Kit 94J45 S S S S
NOTE − Extremes of operating range are plus 10% and minus 5% of line voltage.
1
Sound Rating Number rated in accordance with test conditions included in ARI Standard 270.
2
Refrigerant charge sufficient for 15 ft. length of refrigerant lines.
3
HACR type circuit breaker or fuse.
4
Refer to National or Canadian Electrical Code manual to determine wire, fuse and disconnect size requirements.
