6
Model Power Cord Size
Air Switch
apacity
(A)
Minimum
Sectional Area
of Ground
Wire(mm
2
)
Minimum Sectional
Area of Power
Cord(mm
2
)
VEHW007N432P
VEHW009N432P
VEHW012N432P
VEHW015N432P
VEHW017N432P
VEHW019N432P
VEHW021N432P
VEHW024N432P
208~230V ~ 60Hz 6
1
1
Notes:
① Use copper wire only as unit’s power cord. Operating temperature should be within its
rated value.
② If the power cord is more than 15m long, please increase properly the sectional area of
power cord to avoid overload, which may cause accident.
③ Above selection requirements: Power cord size is based on BV single-core wire (2~4pc) at
40°Cambient temperature when laying across plastic pipe. Air switch is D type and used at 40°C.
If actual installation condition varies, please lower the capacity appropriately according to the
specifications of power cord and air switch provided by manufacturer.
④
If the supply cord is damaged, it must be replaced by the manufacturer or its service agent
or a similarly qualified person in order to avoid a hazard.
⑤
Install cut-off device near the unit. The minimum distance between each stage of cut-off
device should be 3mm(The same for both indoor unit and outdoor unit).
High Wall Type Indoor Unit
