DC Inverter Multi VRF System
8
4 Installation Instruction
NOTE:
Graphics here are only for reference. Please refer to actual products. Unspecified
dimensions are all in mm.
4.1 Dimension of Outdoor Unit and Mounting Hole
Unit Outline and Installation Dimension(mm).
Fig.5
Unit: mm
Model
A
B
C
D
E
VEP042N432U
VEP048N432U
VEP060N432U
900 340 1345 572 378
