Lennox VRB192

29
Figure 26. Outdoor Unit Branch Pipe Kits
Refer to the pipe sizing diagram in the LVSS Calcu-
lation and Selection report to determine pipe sizes.
• Branch pipe kits are used to complete the piping
for connecting outdoor units.
• T-shape connectors are used for balancing
pipes only.
• U-shaped connectors are combined in the eld
to connect refrigerant piping for the structure.
See Figure 26.
Low-Pressure Gas Side Joints (inch) Liquid Side Joints (inch)
Oil Balance
Joint (inch)
Insulation
Material
(furnished)
Name
V
8ODBP02HP-3
V
8ODBP03HP-3
ID:3/4
N
ID:1/4
P
High-Pressure
Gas Balance
Joint (inch)
(2 sets) (4 sets)
ID: 7/8
M
Low-Pressure
Gas Balance
Joint (inch)
Triple-Module Balancing Pipes Only
