Page #15 background imageLoading...
Page #15 background image
15
Auxiliary Heat Relay
Cat # Model # Description
17U44 V0CTRL92P-3 VRF HHE Relay Kit
Network Address and Commissioning
After the system has been installed, each indoor unit must
be assigned an address as part of the commissioning
procedure.
Use the Spot Check Performance tables below and the
Manual button on the unit receiver to view diagnostic
information the indoor unit.
Table 4. Spot Check Performance Identication Table
Spot Check Instructions
This Spot Check Performance table is located on the unit service panel.
The diagnostic information can also be obtained using the wired remote controller.
No. Content Recorded Value/Date
0 Normal display
1 Communication address of indoor unit
2 Indoor unit capacity (horsepower)
3 Network address of indoor unit
4 The actual setpoint temperature
5 The actual indoor temperature T1
6 The middle coil temperature T2
7 The coil inlet temperature T2A
8 The coil outlet temperature T2B
9 The actual superheat temperature
10 The actual subcool temperature
11 Error Code
12 Indoor software version
13 End (--)
