Table 6. XP15−024
INDOOR MATCHUPS
Target
Subcooling
Heat Cool
*Add
charge
g
Heat Cool
(+
5ºF)(+1ºF)
lb oz
CH23−51 14 6 0 14
CBX27UH−030−230 13 6 2 4
CB30U−31 15 5 0 1
CBX32M−030 15 5 0 1
CBX32M−036 13 6 2 4
CBX32MV−024/030 15 5 0 0
CBX32MV−036 13 6 2 4
CBX40UHV−024, −030 15 5 0 0
CBX40UHV−036 13 6 2 4
CH33−42 14 6 0 14
CR33−48 38 7 3 1
CX34−31 15 5 0 1
CX34−38 SN# 6007 and after 6 6 1 15
CX34−38 before SN# 6007 13 6 1 15
Table 7. XP15−030
INDOOR MATCHUPS
Target
Subcooling
Heat Cool
*Add
charge
g
Heat Cool
(+
5ºF)(+1ºF)
lb oz
CR33−48 31 4 0 13
CH23−51 13 5 0 4
CBX27UH−030−230 12 5 0 10
CBX27UH−036−230 13 5 0 8
CB30U−31 14 5 0 0
CB30U−41/46 12 5 0 10
CBX32M−030 14 5 0 0
CBX32M−036 12 5 0 10
CBX32MV−024/030 14 5 0 0
CBX32MV−036 12 5 0 10
CBX40UHV−024, −030 14 5 0 0
CBX40UHV−036 12 5 0 10
CX34−38 SN# 6007 and after 5 5 0 8
CX34−38 before SN# 6007 13 5 0 8
CX34−43 9 5 1 4
CX34−49 6 5 2 0
CX34−50/60C 9 5 1 4
Table 8. XP15−036
INDOOR MATCHUPS
Target
Subcooling
Heat Cool
*Add
charge
g
Heat Cool
(+
5ºF)(+1ºF)
lb oz
C33−44C 13 4 0 3
CBX27UH−036−230 13 4 0 3
CBX27UH−042−230 5 5 0 12
CB30U−41/46 13 4 0 3
CB30U−51 5 5 0 12
CBX32M−042 13 4 0 3
CBX32M−048 5 5 0 12
CBX32MV−036 13 4 0 3
CBX32MV−048 5 5 0 12
CBX40UHV−036 13 4 0 3
CBX40UHV−042, −048 5 5 0 12
CH33−42 14 4 0 1
CH33−44/48B 9 4 0 7
CH33−48C 7 5 0 7
CH33−49C 5 5 0 12
CH33−62D 5 7 0 14
CR33−48C 37 4 0 5
CR33−50/60 32 5 0 10
CX34−31 15 4 0 0
CX34−38 SN# 6007 and after 4 4 0 3
CX34−38 before SN# 6007 13 4 0 3
CX34−43 7 5 0 7
CX34−44/48 13 4 0 3
CX34−49 6 5 0 11
Table 9. XP15−042
INDOOR MATCHUPS
Target
Subcooling
Heat Cool
*Add
charge
g
Heat Cool
(+
5ºF)(+1ºF)
lb oz
C33−44C 13 4 0 0
CH33−62D 7 7 0 13
CBX27UH−042−230 9 4 0 11
CBX27UH−048−230 9 4 0 11
CB30U−51*P 9 4 0 11
CBX32M−048 9 4 0 11
CBX32MV−048 9 4 0 11
CBX40UHV−042, −048 9 4 0 11
CH33−44/48B, −48C 12 4 0 5
CH33−49C 9 4 0 12
CR33−48 35 3 0 2
CX34−38 SN# 6007 and after 4 4 0 0
CX34−38 before SN# 6007 13 4 0 0
CX34−43 12 4 0 5
CX34−44/48B 13 4 0 0
CX34−50/60C 12 4 0 5
Table 10. XP15−048
INDOOR MATCHUPS
Target
Subcooling
Heat Cool
*Add
charge
g
Heat Cool
(+
5ºF)(+1ºF)
lb oz
CH23−68 21 4 0 12
CBX27UH−048−230 22 4 0 3
CBX27UH−060−230 12 4 0 11
CB30U−51*P 22 4 0 3
CB30U−65*P 12 4 0 3
CBX32M−048 22 4 0 3
CBX32M−060 12 4 0 3
CBX32MV−048 22 4 0 3
CBX32MV−060 12 4 0 3
CBX32MV−068 12 4 0 7
CBX40UHV−048 22 4 0 3
CBX40UHV−060 12 4 0 3
CH33−62D 12 4 0 8
CX34−49C 13 4 0 2
CX34−60D 14 4 0 0
CX34−62D 12 4 0 5
Table 11. XP15−060
INDOOR MATCHUPS
Target
Subcooling
Heat Cool
*Add
charge
g
Heat Cool
(+
5ºF)(+1ºF)
lb oz
CH23−68 28 6 0 0
CBX27UH−060−230 17 6 0 0
CB30U−51*P, −65*P 19 6 0 2
CBX32M−048*P, −060*P 19 6 0 2
CBX32MV−048*P, −060*P 19 6 0 2
CBX40UHV−048, −060 19 6 0 2
CH33−62D 18 6 0 1
*Amount of charge required in addition to charge shown on unit
nameplate. (Remember to consider lineset length difference.)
