Lennox ZGB Series User Manual


TABLE 8
ZGB036 NORMAL OPERATING PRESSURES - ALL-ALUMINUM COIL
Outdoor Coil Entering Air Temperature
65 °F 75 °F 85 °F 95 °F 105 °F 115 °F
Suct
(psig)
Disc
(psig)
Suct
(psig)
Disc
(psig)
Suct
(psig)
Disc
(psig)
Suct
(psig)
Disc
(psig)
Suct
(psig)
Disc
(psig)
Suct
(psig)
Disc
(psig)
116 231 119 269 122 311 126 356 129 405 132 458
123 234 127 271 130 313 133 359 137 408 140 462
140 245 144 280 147 321 151 368 155 417 159 171
156 261 160 297 167 338 170 383 173 433 178 489
TABLE 9
ZGB048 NORMAL OPERATING PRESSURES - ALL-ALUMINUM COIL
Outdoor Coil Entering Air Temperature
65 °F 75 °F 85 °F 95 °F 105 °F 115 °F
Suct
(psig)
Disc
(psig)
Suct
(psig)
Disc
(psig)
Suct
(psig)
Disc
(psig)
Suct
(psig)
Disc
(psig)
Suct
(psig)
Disc
(psig)
Suct
(psig)
Disc
(psig)
112 244 115 283 118 326 121 373 124 423 127 480
118 248 122 288 126 331 130 379 133 429 136 177
135 258 138 298 142 341 145 389 150 441 153 496
149 272 154 311 158 355 162 402 166 455 171 193
TABLE 10
ZGB060 NORMAL OPERATING PRESSURES - ALL-ALUMINUM COIL
Outdoor Coil Entering Air Temperature
65 °F 75 °F 85 °F 95 °F 105 °F 115 °F
Suct
(psig)
Disc
(psig)
Suct
(psig)
Disc
(psig)
Suct
(psig)
Disc
(psig)
Suct
(psig)
Disc
(psig)
Suct
(psig)
Disc
(psig)
Suct
(psig)
Disc
(psig)
106 248 110 288 114 331 118 378 123 428 126 483
114 254 118 292 122 336 125 384 129 435 133 493
130 267 134 308 138 353 142 401 146 455 151 511
147 290 151 329 155 372 159 420 164 477 169 533
TABLE 11
ZGB074 NORMAL OPERATING PRESSURES - ALL-ALUMINUM COIL
Outdoor Coil Entering Air Temperature
65 °F 75 °F 85 °F 95 °F 105 °F 115 °F
Suct
(psig)
Disc
(psig)
Suct
(psig)
Disc
(psig)
Suct
(psig)
Disc
(psig)
Suct
(psig)
Disc
(psig)
Suct
(psig)
Disc
(psig)
Suct
(psig)
Disc
(psig)
113 255 116 295 119 340 121 386 125 438 127 493
121 260 124 301 127 345 130 394 133 446 136 502
136 271 140 311 143 353 147 403 150 455 154 512
151 288 157 327 162 372 166 422 169 474 174 540
