Locatingcomponents
Figure4“Componentlocations”onpage14showsthelocationsofthevariouscomponentsinyour
computer.Toremovethecomputercover,see“Removingthecomputercover”onpage36.
Figure4.Componentlocations
1Heatsinkandfanassembly
8Systemfanassembly
2Powersupplyassembly9Thermalsensor
3Memorymodule
10Internalspeaker(availableinsomemodels)
4Opticaldrive11Coverpresenceswitch(intrusionswitch)(availableinsome
models)
5Cardreaderassembly(availableinsome
models)
12Harddiskdriveorsolid-statedrive
6FrontaudioandUSBassembly13PCIcard(availableinThinkCentre
®
M93/pcomputers)
7Frontbezel
14Heatsinkfanduct
Locatingpartsonthesystemboard
•Figure5“ThinkCentreM93/psystemboardpartlocations”onpage15showsthelocationsofthepartson
thesystemboardoftheThinkCentreM93/pcomputer.
•Figure6“ThinkCentreM83systemboardpartlocations”onpage16showsthelocationsofthepartson
thesystemboardoftheThinkCentreM83computer.
14ThinkCentreM83,M93/pUserGuide
