1020 Battery pack

Foraccess,removethisFRU:

• “1010Basecover”onpage32

DANGER

Only use the battery specied in the parts list for your computer. Any other battery

could ignite or explode.

Figure 2. Removal steps of battery pack

Yoga 500-14IBD/Yoga 500-14IHW/Yoga 500-14ACL/

Yoga 500-14ACZ

DisconnecttheFPCconnectorinthedirectionshownbyarrows

and

.

Unplugthebatteryconnectorinthedirectionshownbyarrow

,thenremove

thescrews

.Removethebatterypack

Step Screw (quantity) Color Torque

M2.0×4.0mm,Phillipshead,nylok-coated(2)

BatterytoUCASE(Yoga500-14IBD/

Yoga500-14IHW/Yoga500-14ACL/

Yoga500-14ACZ)

Black 2.0kgf*cm
