Yoga 500-14IBD/Yoga 500-14IHW/Yoga 500-14ACL/Yoga 500-14ACZ/

Yoga 500-15IBD/Yoga 500-15IHW/Yoga 500-15ACL

1140 LCD module

Foraccess,removetheseFRUsinorder:

• “1010Basecover”onpage32

• “1020Batterypack”onpage35

• “1030Harddiskdrive”onpage37

• “1040PCIExpressMiniCardforwirelessLAN”onpage40

• “1060IOboard”onpage43

• “1070Speakers”onpage44

• “1080FanassemblyandHeatSinkassembly”onpage45

• “1090Systemboard”onpage47

• “1100Touchpadmoduleanduppercase”onpage55

• “1110LCDunit”onpage59

• “1120HingesandLCDcover”onpage62

Figure 14. Removal steps of LCD module

Detachthethreeconnectorsinthedirectionsshownbyarrows

When installing:Makesurethattheconnectorsareattachedrmly.
