4
Chapter 2. Parts and locations
Sensors (2) Viewer
Head strap Cable clip
Headphone connector – 3.5 mm (0.14
inches)
Y cable – 4 m (13 feet)
Y-cable USB 3.0 connector Y-cable video connector
Foam cushions (3) Viewer lenses (2)
Viewer hinge Head-strap adjustment knob
Note: If you purchased the Lenovo Explorer headset and controller combo package, refer to
“Chapter 6. Enhancing the Lenovo Explorer” for the parts and locations associated with
controllers.
