Lenovo ideapad 320-15IAP User Manual

41
Lenovo ideapad 320-14IAP/ideapad 320-14AST/ideapad 320-15IAP/ideapad 320-
15AST/ideapad 320-15ABR/ideapad 320-15ABR Touch
1040 PCI Express Mini Card for wireless LAN
Foraccess,removetheseFRUsinorder:
• “1010Opticaldrive”onpage35
• “1020Basecover”onpage36
• “1030Batterypack”onpage39
Important:
The preinstalled WLAN module may only be replaced with a Lenovo approved
module in order to comply with FCC and IC regulations. Refer to Table 4 “Parts
list—Overall” on page 73 for Lenovo part numbers for the approved modules.
Figure 4. Removal steps of PCI Express Mini Card for wireless LAN
DisconnectthetwowirelessLANcables(black,gray)
1
,andthenremovethe
screw
2
.
ideapad 320-15IAP/ideapad 320-15AST/ideapad 320-15ABR/
ideapad 320-15ABR Touch
aa
b
ideapad 320-14IAP/ideapad 320-14AST
aa
b

Lenovo ideapad 320-15IAP Specifications

General

Operating System	Windows 10 Home
Weight	2.2 kg (4.85 lbs)
Dimensions	378 x 260 x 22.9 mm (14.88 x 10.24 x 0.9 inches)
Wireless	802.11ac Wi-Fi, Bluetooth 4.1
Processor	Intel Pentium N4200
Display	15.6-inch, HD (1366x768)
RAM	4GB DDR4
Storage	500GB HDD
Graphics	Intel HD Graphics 505
Battery	2-cell, 30Wh
Ports	2 x USB 3.0, HDMI, SD card reader, headphone/mic combo
Color	Platinum Grey
