Lenovo ideapad 320-15IAP User Manual

68
ideapad 320-14IAP/ideapad 320-14AST/ideapad 320-15IAP/ideapad 320-15AST/ideapad
320-15ABR/ideapad 320-15ABR Touch Hardware Maintenance Manual
Locations
Front view and right-side view
1
 Integratedcamera
2
 Built-inmicrophone
3
 Computerdisplay
4
 WirelessLANantennas
5
 PowerKey
6
 Touchpad
7
 Opticaldiscdrive
8
 KensingtonSecurityslot
f
c
e
h
g
d
a
b

Lenovo ideapad 320-15IAP Specifications

General

Operating System	Windows 10 Home
Weight	2.2 kg (4.85 lbs)
Dimensions	378 x 260 x 22.9 mm (14.88 x 10.24 x 0.9 inches)
Wireless	802.11ac Wi-Fi, Bluetooth 4.1
Processor	Intel Pentium N4200
Display	15.6-inch, HD (1366x768)
RAM	4GB DDR4
Storage	500GB HDD
Graphics	Intel HD Graphics 505
Battery	2-cell, 30Wh
Ports	2 x USB 3.0, HDMI, SD card reader, headphone/mic combo
Color	Platinum Grey
