Lenovo Legion 7 16ACHg6 User Manual

Figure 15. Remove the Wi-Fi card
Screw specifications
Number of screws
M2 x L3.5 1
Go to
https://support.lenovo.com/partslookup to look up the Lenovo part number of the following replacement
part:
Wi-Fi card
Remove the CMOS battery
Make sure the following FRUs (or CRUs) have been removed.
“Remove the lower case” on page 28
“Remove the solid-state drive (SSD) plate L” on page 29
Step 1. Remove the left SSD.
Note: For details, see “Remove the solid-state drive (SSD)” on page 31.
Step 2. Disconnect the CMOS battery cable from the system board and then remove the CMOS battery.
Figure 16. Remove the CMOS battery
Chapter 4. Removing a FRU or CRU 35

Lenovo Legion 7 16ACHg6 Specifications

General

RAM	Up to 32GB DDR4 3200MHz
Battery	80Wh
Operating System	Windows 10 Home
Processor	AMD Ryzen 7 5800H / Ryzen 9 5900HX
Graphics	NVIDIA GeForce RTX 3080
Display	16" WQXGA (2560 x 1600), IPS, 165Hz
Storage	Up to 2TB SSD
Weight	2.5 kg
Audio	2 x 2W Harman speakers, Nahimic Audio
Webcam	720p with E-shutter
Keyboard	RGB backlit
Ports	HDMI 2.1
Wireless	Wi-Fi 6 (802.11ax), Bluetooth 5.1
