1060 PCI Express Mini Card for 802.11 a/b/g wireless LAN
For access, remove these FRUs in order:
v “1010 Battery pack” on page 45
v “1040 DIMM slot cover” on page 47
2
1
1
3
Step Screw (quantity) Color Torque
1 M2 × 3 mm, pan-head, nylon-coated (2) Black 0.245 Nm
(2.5
kgfcm)
In step 2, unplug the jacks by using the removal tool antenna RF connector
(P/N: 08K7159) or pick the connectors with your fingers and gently unplug them
in direction of the arrow.
When installing: Plug the gray cable into the jack labeled MAIN on the card, and
the black cable into the jack labeled AUX.
Removing and replacing a FRU
Lenovo 3000 N200 49

Lenovo N200 Specifications

General

Battery	6-cell Li-Ion
Display Size	15.4 inches
Resolution	1280 x 800
Storage	120GB HDD
Operating System	Windows Vista
Optical Drive	DVD-RW
Wireless	802.11b/g
Ports	3 x USB 2.0, VGA, Headphone, Microphone
Processor	Intel Celeron M 530 (1.73GHz)
