2030 Integrated camera
For access, remove these FRUs in order:
v “1010 Battery pack” on page 45
v “2010 LCD front bezel” on page 73
Note:
The part marked a is fragile and might be damaged by rough handling.
When you remove the camera, do not hold that part to avoid the damage.
1
1
3
2
a
Step Screw (quantity) Color Torque
1 M2 × 3 mm, flat-head, nylon-coated (2) Silver 0.245 Nm
(2.5 kgfcm)
When installing: Make sure that connectors 3 and 4 are attached firmly.
Removing and replacing a FRU
Lenovo 3000 V100 75
