Lenovo Smart Clock 2 - Overview; Product Components Overview

Overview
Name Model
Lenovo Smart Clock 2 Lenovo CD-24502F
5 5
7 6
1 1 42
3
1
Microphones
2
Light/proximity
sensor
3
Touch screen
4
Dock connector
5
Volume buttons
6
Microphone mute
switch
7
Power adapter
connector
• All pictures and illustrations in this document are for your
reference only and may differ from the final product.
• To mute the microphone, slide the Microphone mute switch to
the left.
