Lenovo TAB 7 - Device Overview; Device Components

1
The WLAN version (Lenovo TB-7504F) does not have a Nano-SIM card slot.
All pictures and illustrations in this document are for your reference only and may
differ from the final product.
Device overview
Model Version
Lenovo TB-7504F WLAN
Lenovo TB-7504X WLAN + LTE
1
Front camera
2
Speaker/Receiver
3
Indicator
4
Touch screen
5
Power button
6
Volume buttons
7
Rear camera
8
Micro USB connector
9
Headset connector
10
Card tray
11
Microphone
1
2
5
3
5
6
7
8
9
10
11
4
