Locations
Thissectionprovidesinformationtohelpyoulocatetheconnectorsonthefrontandrearofyourcomputer.
Note:Thecomponentsinyourcomputermightlookslightlydifferentfromtheillustrations.
Locatingconnectors,controls,andindicatorsonthefrontofyour
computer
Figure1“Frontconnector,control,andindicatorlocations”onpage8showsthelocationsoftheconnectors,
controls,andindicatorsonthefrontofyourcomputer.
Figure1.Frontconnector,control,andindicatorlocations
1Integratedmicrophone2Integratedcameraindicator
3Integratedcamera4Poweronindicator
5Internalspeaker
6Cardreader(availableinsomemodels)
7USB3.0connector(USBconnector2)
8Headphoneconnector
9Microphoneconnector
10USB3.0connector(USBconnector1)
