Lenovo ThinkPad E590 - Page 53

6. Remove the screw 1 that secures the M.2 solid-state drive. Then, remove the M.2 solid-state drive out
of the slot
2 .
Note: Remove the short bracket if you want to replace the short M.2 solid-state drive with a long M.2
solid-state drive.
Chapter 6. CRU replacement 47
