Locatingconnectorsandcontrolsonthedock

Thefollowingillustrationhelpsyoulocatetheconnectorsandcontrolsonthedock.

Figure1.Overviewofthedock

1Powerindicator8Powerconnector

2Headset/microphonecomboconnector9GigabitEthernetconnector

3USB3.0connectorwithbatterychargingfunction10USB3.0connectors

4USB3.0connector

11Powerbutton

5Security-lockslot12USB2.0connectors

6OneLinkcable

13DisplayPortconnector

7Cablemanagementstand

14DVI-Iconnector

1Powerindicator

Thepowerindicatorisusedtoindicatethepowerstatusofthenotebookcomputerthatconnectswiththe

dock.

•Ifthepowerindicatorislitinred,itindicatesthatthenotebookcomputeristurnedon.

•Ifthepowerindicatorisoff,itindicatesthatyournotebookcomputeristurnedoff,insleepmode,orin

hibernationmode;orthedockisdisconnectedfromyournotebookcomputer.

2Headset/microphonecomboconnector

Theheadset/microphonecomboconnectorisusedtoconnectaheadset,amicrophone,oraspeaker.

2ThinkPadOneLinkProDockUserGuide
