Table56.RemovalstepsofsecondLCDcableassembly(forThinkPadW701ds)(continued)
2090SecondLCDhingesandsecondLCDrearcover(secondLCDcover
kit)(forThinkPadW700dsandW701ds)
Foraccess,removetheseFRUsinorder:
•“1010Batterypack”onpage68
•“1040Harddiskdrive(HDD)cover,HDDandHDDrubberrailsorsolidstatedrive(SSD)andstorage
converter”onpage70
•“1060Palmrestorpalmrestwithngerprintreader”onpage75
•“1090Keyboard”onpage80
146ThinkPadW700,W700ds,W701,andW701dsHardwareMaintenanceManual
