4.
Secure
the
keyboar
d
by
tightening
the
screws
fr
om
the
bottom
side
of
the
computer
.
1070
P
alm
rest
F
or
access,
remove
these
FRUs
in
or
der:
•
“1020
Battery
pack”
on
page
63
•
“1060
Keyboard”
on
page
68
Removal
steps
of
palm
rest
Step
Icon
Screw
(quantity)
Color
T
orque
1
M2
×
6
mm,
wafer-head,
nylon-coated
(5)
Black
0.181
Nm
(1.85
kgfcm)
Chapter
8
.
Removing
and
r
eplacing
a
FRU
71
76
78
