Lenovo ThinkServer TS140 Quick Reference Guide

THINKSERVER SA120 SERIES SUMMARY
Specifications SA120
FORM FACTOR
Chassis 2U rack chassis – static rail kit included
POWER
Power: choices 1 + 1 hot-swap redundant
Power: capacity 550W
Power: eciency 80 PLUS Gold
COOLING
Fans 2 hot-swap redundant
STORAGE AND CONTROLLERS
I/O controllers Up to 2 ThinkServer Storage Array 6Gbps I/O Modules
Storage: max capacity front panel 48TB (12 x 3.5" 6Gbps SAS)
Storage: max capacity rear panel* 3.2TB (4 x 2.5" 6Gbps SATA SSD)
Storage: config. choices
Up to 4TB 3.5" SAS 7.2K 6Gbps hot-swap HDD
Up to 800GB Value Read Optimized 2.5" SATA 6Gbps hot-swap SSD
Up to 800GB Mainstream Multipurpose 2.5" SATA 6Gbps hot-swap SSD
RAID: levels supported 0/1/5/6/10/50/60/JBOD
RAID: adapter compatibility
ThinkServer LSI9280-8e 6Gbps SAS RAID HBA by LSI (0,1,5,6,10,50,60)
ThinkServer LSI9286CV-8e 6Gbps SAS RAID HBA by LSI (0,1,5,6,10,50,60)
ThinkServer LSI9207-8e 6Gbps SAS HBA by LSI (Available spring 2014)
MANAGEMENT
Soware LSI MegaRAID Storage Manager
OTHER
Back panel: connectors
1 SAS (SFF 8088) in connector
1 SAS (SFF 8088) out connector
1 RJ11 serial port
* Configuring 2.5" drives on rear panel requires optional ThinkServer 2.5" SATA
SSD Cage with SATA Interposer (part number 4XFOF28766).

Lenovo ThinkServer TS140 Specifications

General

Processor Cores	4 cores
Chipset	Intel C226
Memory Slots	4 DIMM slots
Form Factor	Tower
Processor	Intel Xeon E3-1200 v3 series
Memory	Up to 32GB DDR3
Storage	Up to 4 x 3.5" drives
RAID Support	RAID 0, 1, 10
Expansion Slots	1 x PCIe 3.0 x16
Network	Integrated Intel Gigabit Ethernet
Power Supply	280W
Operating System Support	Windows Server, Red Hat Linux, SUSE Linux
