Lenovo ThinkServer TS140 Quick Reference Guide

THINKSERVER SERIES SUMMARY
Family Specifications TS140 / TS440 TD340 RD340 / RD440 RD540 / RD640
PERFORMANCE
Chipset Intel C226 Intel C606 Intel C606 Intel C602-J
CPU: sockets 1 2 2 2
CPU: choices
Intel E3-1200 v3, Core i3, or
Pentium
Intel Xeon E5-2400
v2
Intel Xeon E5-2400 v2 Intel Xeon E5-2600 v2
CPU: max. power 95W 95W 95W 130W
Memory: sockets 4 12 12 20
Memory: capacity 32GB (4 x 8GB) 192GB (12 x 16GB) 192GB (12 x 16GB) 320GB (20 x 16GB)
Memory: choices UDIMM UDIMM, LV RDIMM LV RDIMM RDIMM, LV RDIMM
POWER
Power: choices 1 x fixed
1 fixed or 1 + 1
hot-swap
redundant
1 x fixed or 1 + 1
hot-swap redundant
1 + 1 hot-swap redundant 1 + 1 hot-swap redundant
Power: capacity
280W (common
configurations)
450W (for
>2HDD
or GFX card)
400W or 450W 625W or 800W 550W 800W 800W
Power: eciency 80 PLUS Gold
80 PLUS Bronze or
80 PLUS Gold
80 PLUS Gold 80 PLUS Gold
STORAGE AND CONTROLLERS
Storage: max. capacity 16TB (4 x 4TB) 32TB (8 x 4TB) 32TB (8 x 4TB) 16 (4 x 4TB) 48TB (12 x 4TB) 16TB (4 x 4TB) 32TB (8 x 4TB)
Storage: hot swap choices Fixed
Fixed or hot-
swap
Fixed or hot-swap Hot-swap Hot-swap
Storage: config. choices 4 x 3.5"
4 x 3.5", 8 x 3.5"
or 8 x 2.5"
4 x 3.5", 8 x 3.5",
8 x 2.5" or 16 x 2.5"
4 x 3.5", 6 x 2.5"
or 8 x 2.5"
8 x 3.5", 12 x 3.5",
8 x 2.5" or 16 x 2.5"
4 x 3.5", 6 x 2.5"
or 8 x 2 .5"
8 x 3.5", 8 x 2.5"
or 16 x 2.5"
Storage: 3.5" capacity 16TB (4 x 4TB) 32TB (8 x 4TB) 32TB (8 x 4TB) 16TB (4 x 4TB) 48TB (12 x 4TB) 16TB (4 x 4TB) 32TB (8 x 4TB)
Storage: 2.5" capacity n/a 4.8TB 16TB (16 x 1TB) 8TB (8 x 1TB) 16TB (16 x 1TB) 8TB (8 x 1TB) 16TB (16 x 1TB)
Storage: SSD capacity n/a n/a 3.2TB (8 x 400GB)
3.2TB
(8 x 400GB)
3.2TB
(8 x 400GB)
3.2TB
(8 x 400GB)
3.2TB
(8 x 400GB)
Storage: optical drive
Standard or
Slim ODD
Standard ODD Standard ODD
Slim ODD (for
3.5" chassis)
Slim ODD
Slim ODD (for
3.5" chassis)
Slim ODD
RAID: onboard Soware 0/1/5/10 Soware 0/1/10 Soware 0/1/10 Hardware 0/1/10
NETWORKING AND MANAGEMENT
Ethernet 1 2 2 + 1 2 + 1
Expansion • 1 x PCIe
GEN3: HH/
FL x16
mechanical,
x16 electrical
• 1 x PCIe
GEN2:
HH/HL x1
mechanical,
x1 electrical
• 1 x PCIe
GEN2: HH/
HL x16
mechanical,
x4 electrical
• 1 x PCI
32bit/33MHz:
FH/HL
• 1 x PCIe GEN3:
HH/FL x16
mechanical,
x16 electrical
• 1 x PCIe GEN2:
HH/HL x16
mechanical,
x4 electrical
• 1 x PCIe GEN2:
HH/HL x1
mechanical,
x1 electrical
• 1 x PCI 5V
32bit/33 MHz:
FH/HL
With 1 CPU
installed:
• 1 x PCI: FH/HL 5V
32-bit/33MHz
• 1 x PCIe Gen3: FH/
HL x8 mechanical,
x4 electrical
• 1 x PCIe Gen3: FH/
HL x16 mechanical,
x16 electrical
With 2 CPUs
installed:
• 1 x PCI: FH/HL 5V
32-bit/33MHz
• 1 x PCIe Gen3: FH/
HL x8 mechanical,
x4 electrical
• 3 x PCIe Gen3: FH/
HL x8 mechanical,
x8 electrical
• 1 x PCIe Gen3: FH/
HL x16 mechanical,
x16 electrical
With 1 CPU
installed:
• 1 x PCIe
Gen3: LP x8
mechanical,
x4 electrical
• 1 x PCIe Gen3:
FH/HL x16
mechanical,
x16 electrical
With 2 CPUs
installed:
• 1 x PCIe
Gen3: LP x8
mechanical,
x8 electrical
• 1 x PCIe Gen3:
FH/HL x16
mechanical,
x16 electrical
With 1 CPU
installed:
• 1 x PCIe Gen3:
FH/HL x16
mechanical,
x8 electrical
• 1 x PCIe Gen3:
FH/HL x8
mechanical,
x8 electrical
• 1 x PCIe Gen3:
LP x8 mechanical,
x4 electrical
• 1 x PCIe Gen3:
FH/HL x8
mechanical,
x4 electrical
With 2 CPUs
installed:
• 2 x PCIe Gen3:
FH/HL x16
mechanical,
x8 electrical
• 2 x PCIe Gen3:
FH/HL x8
mechanical,
x8 electrical
• 1 x PCIe Gen3:
LP x8 mechanical,
x4 electrical
• 1 x PCIe Gen3:
FH/HL x8
mechanical, x4
electrical
• 1 x PCIe
Gen3: LP x8
mechanical,
x8 electrical*
• 1 x PCIe
Gen3: FH/
HL x16
mechanical,
x16 electrical
With 1 CPU
installed:
• 1 x PCIe Gen3:
FH/HL x16
mechanical,
x16 electrical*
• 1 x PCIe
Gen3: LP x8
mechanical,
x8 electrical
• 2 x PCIe Gen3:
FH/HL x8
mechanical,
x8 electrical
With 2 CPUs
installed:
• 1 x PCIe Gen3:
FH/HL x16
mechanical,
x16 electrical*
• 1 x PCIe
Gen3: LP x8
mechanical,
x8 electrical
• 3 x PCIe Gen3:
FH/HL x8
mechanical,
x8 electrical
• 1 x PCIe Gen3:
FH/HL x16
mechanical,
x8 electrical
Management Intel AMT™ 9.0 (Xeon models)
TMM (IMPMI
2.0-compliant)
TMM (IPMI 2.0-compliant) TMM (IPMI 2.0-compliant)
Remote Management
1
Intel AMT™ 9.0 (Xeon models)
(Optional)
Optional ThinkServer
Management Module
Premium (iKVM)
Optional ThinkServer Management
Module Premium (iKVM)
Optional ThinkServer Management
Module Premium (iKVM)
Smart Grid supported? No No Yes Yes
1
AMT KVM feature available only for Xeon processors with integrated graphics
* Populated with hardware RAID adapter

Lenovo ThinkServer TS140 Specifications

General

Processor Cores	4 cores
Chipset	Intel C226
Memory Slots	4 DIMM slots
Form Factor	Tower
Processor	Intel Xeon E3-1200 v3 series
Memory	Up to 32GB DDR3
Storage	Up to 4 x 3.5" drives
RAID Support	RAID 0, 1, 10
Expansion Slots	1 x PCIe 3.0 x16
Network	Integrated Intel Gigabit Ethernet
Power Supply	280W
Operating System Support	Windows Server, Red Hat Linux, SUSE Linux
