Lenovo ThinkServer TS150 User Manual

Date of purchase
______________________________________________
Server documentation
This topic provides a general description of each document for your server and instructions on how to obtain
all the documents.
Printed documents
Your server package contains the following printed documents:
• Read Me First
This is a multilingual document. It illustrates safety symbols and instructs you to read the complete safety,
warranty, and support information provided on the Lenovo Web site before using the server. This
document also tells you how to find the most up-to-date information on the Lenovo Support Web site. In
addition, recycling, environmental, and legal notices are all included.
• A letter to customers
This is a multilingual letter to customers, which tells customers that Lenovo is undertaking a paperless
electronic documentation initiative to protect environment. This letter also provides information about how
to contact Lenovo if you require a printed version of any electronic documents.
Electronic documents
• You can find the following electronic documents at
https://support.lenovo.com/documents/LNVO-DOCS:
– Safety Information
This is a multilingual document that includes all the safety statements for your product. Ensure that you
read and understand these safety statements before using the product.
– Lenovo Limited Warranty
This document includes the Lenovo terms and warranty statements.
– Lenovo License Agreement
This document includes the terms and conditions of the Lenovo License Agreement.
• You can find the following electronic documents from the Lenovo Support Web site. Go to
http://
www.lenovo.com/support
, click Documentation, and follow the instructions on the screen to find the
document you need.
– Safety, Warranty, and Support Information
This is a multilingual document that includes all the safety statements for your product in more than 30
languages. Ensure that you read and understand all the safety statements before using the product.
This document also includes the Lenovo warranty statement, Customer Replaceable Units (CRUs)
information, and information about how to contact the Lenovo Customer Support Center.
– User Guide and Hardware Maintenance Manual
This document provides detailed information to help you get familiar with your server and help you use,
configure, and maintain your server.
– MegaRAID SAS Software User Guide (English only)
This document provides information about Redundant Array of Independent Disks (RAID) and how to
use the utility programs to configure, monitor, and maintain your server RAID and related devices.
2
ThinkServer TS150 User Guide and Hardware Maintenance Manual

Lenovo ThinkServer TS150 Specifications

General

Bus type	DMI3
Scalability	1S
Processor cache	8 MB
Processor cores	4
Processor model	E3-1225V5
System bus rate	8 GT/s
Processor series	Intel Xeon E3-1200 v5
Processor socket	LGA 1151 (Socket H4)
Processor codename	Skylake
Execute Disable Bit	Yes
Processor frequency	3.3 GHz
Processor cache type	Smart Cache
Processor lithography	14 nm
Processor manufacturer	Intel
Processor package size	37.5 x 37.5 mm
Processor boost frequency	3.7 GHz
Processor operating modes	64-bit
PCI Express configurations	1x16, 1x8+2x4, 2x8
Supported instruction sets	AVX 2.0, SSE4.1, SSE4.2
Thermal Design Power (TDP)	80 W
Number of processors installed	1
Maximum number of PCI Express lanes	16
Memory types supported by processor	DDR3L-SDRAM, DDR4-SDRAM
Memory voltage supported by processor	1.35 V
Memory channels supported by processor	Dual
Memory clock speeds supported by processor	1333, 1600, 1866, 2133 MHz
Memory bandwidth supported by processor (max)	34.1 GB/s
Maximum internal memory supported by processor	64 GB
HDD size	3.5 \
RAID levels	0, 1, 5, 10
HDD interface	Serial ATA
Optical drive type	DVD-ROM
Total storage capacity	2000 GB
Maximum storage capacity	24 TB
Number of HDDs installed	2
Internal memory	8 GB
Memory clock speed	2133 MHz
Internal memory type	DDR4-SDRAM
Memory layout (slots x size)	1 x 8 GB
On-board graphics card ID	0x191D
On-board graphics card model	Intel® HD Graphics P530
On-board graphics card family	Intel® HD Graphics
Maximum on-board graphics card memory	1.7 GB
On-board graphics card OpenGL version	4.4
On-board graphics card base frequency	400 MHz
On-board graphics card DirectX version	12.0
On-board graphics card dynamic frequency (max)	1150 MHz
Number of displays supported (on-board graphics)	3
Cabling technology	10/100/1000Base-T(X)
Ethernet interface type	Gigabit Ethernet
USB 2.0 ports quantity	0
USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity	8
PCI Express slots version	3.0
Operating altitude	0 - 3048 m
Storage temperature (T-T)	-40 - 60 °C
Operating temperature (T-T)	10 - 35 °C
Storage relative humidity (H-H)	10 - 90 %
Operating relative humidity (H-H)	8 - 80 %
Power supply	400 W
Power supply input frequency	50 - 60 Hz
Redundant power supply (RPS) support	-
Chassis type	Tower
Operating system installed	Windows Server 2012 Foundation
Compatible operating systems	Windows Server 2012/2012 R2, Red Hat Enterprise Linux, SUSE Linux 11/12, Windows 10, Canonical Ubuntu 14.04, VMware vSphere 2015
Processor ARK ID	88168
Intel Secure Key Technology version	1.00
Intel® Hyper Threading Technology (Intel® HT Technology)	No

Weight and Dimensions

Depth	431 mm
Width	175 mm
Height	375 mm
Weight	12500 g
