Lenovo ThinkServer TS150 - Page 29

Figure 6. Server components
1 Heat sink and fan assembly
3
2 System board
3
3 CPU
3
4 Memory modules
1
5 Optical drive*
1
6 ThinkServer TS150 3.5" HDD to 5.25" Tray Convertor
with Slim ODD Kit*
2
7 RDX tape drive*
1
8 ThinkServer TS150 3.5" HDD to 5.25" Tray Convertor
Kit*
2
9 Thermal sensor
2
10 Front bezel
2
11 Front USB assembly
2
12 Secure digital (SD) module*
2
13 Front fan assembly
2
14 Hard disk drive or solid-state drive
1
15 Coin-cell battery
1
16 ThinkServer TS150 FDD to 2.5'' HDD Convertor Kit*
2
17 PCIe card*
1
18 Intrusion switch*
1
19 Rear fan assembly
2
20 Power supply assembly
2
Chapter 3. Product overview 17
